Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Sektor
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
612 Select CroMoly steel. Double butted down, top, and seat tubes. Externally tapered, ovalized, and dimpled chain stays, tapered seat stays, replaceable derailleur hanger. Stealth dropper post routing.
Suspension Fork
RockShox SEKTOR 120mm 29er Boost
Drivetrain
Rear Derailleur
SRAM NX-Eagle
Front Derailleur
N/A
Shift Levers
SRAM NX-Eagle
Cassette
SRAM PG1230 Eagle 11-50
Crank
SRAM NX-Eagle 32t, DUB, Boost
Bottom Bracket
SRAM DUB
Chain
SRAM NX-Eagle
Wheels
Front Hub
WTB Boost 110/148, 32h
Rear Hub
WTB Boost 110/148, 32h
Rims
WTB ST i40, 27.5, 32h
Tires
WTB Ranger 27.5 x 2.8", TCS
Brakes
Brakes
SRAM Level, 180mm/160mm Centerline Rotors
Cockpit
Stem
Promax 3D Forged Stem, 60mm
Handlebar
Salsa Rustler, 700mm/750mm/800mm
Grips
Locking Grip, Black
Headset
Cane Creek 40 Series
Seat
Saddle
All-City Gonzo
Seatpost
TranzX YSP12 Dropper, 100mm travel, underbar thumb lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.63 mm | 1.5 mm | 1.43 mm | 1.37 mm | 1.34 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 648 mm | 688 mm | 719 mm | 750 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 91 mm | 91 mm | 91 mm | 91 mm | 91 mm |
| Stack | 601.1 mm | 610.7 mm | 620.2 mm | 629.7 mm | 639.1 mm |
| Reach | 369.9 mm | 407.1 mm | 434.2 mm | 461.3 mm | 478.3 mm |
| Top Tube Length | 569.5 mm | 609.5 mm | 639.6 mm | 669.6 mm | 689.7 mm |
| Seat Tube Angle | 71.4 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Seat Tube Length | 356 mm | 400 mm | 445 mm | 483 mm | 525 mm |
| Head Tube Angle | 67.6 ° | 67.7 ° | 67.7 ° | 67.7 ° | 67.7 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1076 mm | 1117 mm | 1147 mm | 1178 mm | 1199 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 708 mm | 745 mm | 779 mm | 812 mm | 843 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Electric Queen completes the Allcity Queen model. There are 4 bikes that carry this model name. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2399$. Comparing the average cost of a Trail bike to this one, you will see that Electric Queen price is 15.13% lower.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The RockShox Sektor is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Electric Queen 2020 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Electric Queen has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
All City Electric Queen comes with a dropper post. Therefore, climbing or descending will be a breeze.
