Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset Apex, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
612 Select CroMoly steel. Double-butted down, top, & seat tubes. Externally tapered, ovalized, & dimpled chain stays, tapered seat stays, replaceable derailleur hanger.
Suspension Fork
4130 CroMoly tapered fork blades, lugged crown & matching dropout, straight steertube, IS disc brake tabs.
Drivetrain
Rear Derailleur
SRAM Apex 10-spd WiFli (32t max)
Front Derailleur
SRAM Apex 2x braze-on w/band clamp (28.6mm)
Shift Levers
SRAM Apex 2x10-speed shift/brake levers
Cassette
10-speed, 11-32t
Crank
FSA Omega Exo 50/34
Bottom Bracket
SRAM Power Spline
Chain
SRAM PC10
Wheels
Front Hub
Joytech QR, 32h, 6-bolt rotor
Rear Hub
Joytech QR, 32h, 6-bolt rotor
Rims
WTB STP i19 TCS, (650b in 43/46cm, 700c in larger sizes)
Tires
VEE Speedster
Brakes
Brakes
Promax mechanical disc, 160mm rotors
Cockpit
Stem
3D forged, 4-bolt stem, 31.8mm
Handlebar
AL6061, 31.8mm, 80mm reach, 125mm drop
Headset
Cane Creek 10 Series
Seat
Saddle
All-City Gonzo
Seatpost
27.2mm, 2-bolt, 350mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43cm | 46cm | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.35 mm | 1.45 mm | 1.48 mm | 1.55 mm | 1.58 mm | 1.57 mm |
| Front Center | 573 mm | 585 mm | 595 mm | 604 mm | 600 mm | 615 mm | 639 mm |
| Rake | 49 mm | 49 mm | 52 mm | 52 mm | 47 mm | 47 mm | 47 mm |
| Trail | 68 mm | 65 mm | 65 mm | 65 mm | 64 mm | 64 mm | 64 mm |
| Stack | 496 mm | 507 mm | 548 mm | 562 mm | 592 mm | 615 mm | 639 mm |
| Reach | 362 mm | 375 mm | 377 mm | 381 mm | 382 mm | 390 mm | 406 mm |
| Top Tube Length | 498 mm | 518 mm | 533 mm | 548 mm | 563 mm | 583 mm | 613 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.2 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm | 600 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 95 mm | 105 mm | 110 mm | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 423 mm | 423 mm | 438 mm | 443 mm | 443 mm | 448 mm | 448 mm |
| Wheelbase | 988 mm | 1001 mm | 1021 mm | 1035 mm | 1032 mm | 1052 mm | 1076 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 712 mm | 735 mm | 760 mm | 783 mm | 812 mm | 838 mm | 864 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Space Horse completes the Allcity Space model. All City released 14 bikes variations of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When All City released this model in 2019, its price was 1499$. Comparing this to the average Gravel bike price, we see that the price is 64.24% lower.
Overview of components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, All City Space Horse 2019, has a aluminum model. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Space Horse comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
