Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All-City A.C.E. Air-Hardened, Custom, Extruded steel frame, Custom tapered headtube with external headset
Suspension Fork
Whisky No.9 thru-axle, carbon blades, tapered carbon steerer tube, Post Mount Disc Brake mount
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7000 w/ Hydro Brakes
Cassette
Shimano R7000 11-32
Crank
Shimano 105 R7000 52-36
Bottom Bracket
Shimano RS500
Chain
Shimano HG601
Wheels
Front Hub
All-City Go-Devil 28h
Rear Hub
All-City Go-Devil 28h
Rims
WTB ST Light i19
Tires
Teravail Rampart 700x28 60tpi Light and Supple
Brakes
Brakes
Shimano 105 R7000 Flat Mount Calipers w/ 6 bolt SM-RT26 160 rotors
Cockpit
Stem
Whisky No. 7
Handlebar
Whisky No. 7
Grips
All-City Super-Cush w/ Locking Alloy All-City End Plugs
Headset
Cane Creek 40 Series
Seat
Saddle
All-City Gonzo
Seatpost
Whisky No. 7
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 270 mm | 270 mm | 271 mm | 271 mm |
| Front Center | 598 mm | 601 mm | 605 mm | 613 mm | 632 mm | 654 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 71 mm | 60 mm | 53 mm | 58 mm | 49 mm | 49 mm |
| Stack | 516 mm | 532 mm | 554 mm | 575 mm | 599 mm | 623 mm |
| Reach | 367 mm | 369 mm | 376 mm | 381 mm | 392 mm | 407 mm |
| Top Tube Length | 512 mm | 522 mm | 537 mm | 552 mm | 572 mm | 597 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 412 mm | 412 mm |
| Wheelbase | 995 mm | 998 mm | 1003 mm | 1011 mm | 1035 mm | 1057 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 66 mm | 66 mm | 65 mm | 65 mm |
| Standover Height | 728 mm | 753 mm | 779 mm | 805 mm | 832 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Zig Zag 105 belongs to the Allcity Zig model. There are 11 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
All City Zig Zag 105 2019 is the most affordable bike of this model and has a price of 2699$. On the other hand, All City Zig Zag Ultegra 2019, is the most expensive and costs 3999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, All City Zig Zag 105 price was 2699$. In conclusion, this bike price is 15.05% higher than the price of the average Endurance bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When leaving the production line, the Zig Zag 105 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. All City Zig Zag 105 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
