Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All-City A.C.E. Air-Hardened, Custom, Extruded steel frame, Custom tapered headtube with external headset
Suspension Fork
Whisky No.9 thru-axle, carbon blades, tapered carbon steerer tube, Flat Mount Disc Brake mount
Drivetrain
Rear Derailleur
Shimano 105 R7000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano 105 R7000 w/ Hydro Brakes
Cassette
Shimano R7000 11-32
Crank
Shimano 105 R7000 52-36
Bottom Bracket
Shimano RS500
Chain
Shimano HG601
Wheels
Front Hub
All-City Go-Devil 32h
Rear Hub
All-City Go-Devil 32h
Rims
WTB ST Light i19
Tires
Teravail Rampart 700x28 60tpi Light and Supple
Brakes
Brakes
Shimano 105 R7000 Flat Mount Calipers w/ 6 bolt SM-RT26 160 rotors
Cockpit
Stem
Whisky No. 7
Handlebar
Whisky No. 7
Grips
All-City Super-Cush w/ Locking Alloy All-City End Plugs
Headset
Cane Creek 40 Series
Seat
Saddle
All-City Gonzo
Seatpost
Whisky No. 7
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.51 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm | 266 mm |
| Front Center | 598 mm | 602 mm | 606 mm | 614 mm | 633 mm | 655 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 69 mm | 58 mm | 51 mm | 55 mm | 47 mm | 47 mm |
| Stack | 516 mm | 532 mm | 554 mm | 575 mm | 599 mm | 623 mm |
| Reach | 367 mm | 369 mm | 376 mm | 381 mm | 392 mm | 407 mm |
| Top Tube Length | 512 mm | 522 mm | 537 mm | 552 mm | 572 mm | 597 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm | 610 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 106 mm | 121 mm | 140 mm | 160.5 mm | 185.5 mm | 210.5 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 412 mm | 412 mm |
| Wheelbase | 995 mm | 998 mm | 1003 mm | 1011 mm | 1035 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 728 mm | 753 mm | 779 mm | 805 mm | 832 mm | 858 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Zig Zag 105 belongs to the Allcity Zig model. 11 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
All City Zig Zag 105 2020 is the cheapest bike model and costs 2499$. All City Zig Zag Ultegra 2020 is the most expensive one and costs 3999$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Endurance bikes average price
According to our math, the average price for a trustworthy Endurance bike is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2499$. Comparing the average cost of an Endurance bike to this one, you will see that Zig Zag 105 price is 6.52% more expensive.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
As for the wheels, All City Zig Zag 105 2020, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Zig Zag 105 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
