Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset X01 Eagle AXS, Force eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS
Shift Levers
SRAM Force AXS
Cassette
SRAM XG-1295 Eagle 10-50
Crank
SRAM Force D1 1x Crankset 42t
Bottom Bracket
SRAM DUB
Chain
SRAM X01 Eagle
Wheels
Rims
Industry Nine UL250 CX 700 Wheelset - XDR
Tires
WTB Resolute 700x42 TCS 120tpi SG2
Brakes
Brakes
SRAM Force HRD
Cockpit
Stem
FSA Energy SCR Stem
Handlebar
FSA K-Wing AGX Carbon Handlebar
Seat
Saddle
Ergon SR10 Sport
Seatpost
FSA SL-K Carbon Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 599 mm | 609 mm | 619 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 77 mm | 65 mm | 66 mm | 72 mm | 72 mm |
| Stack | 535 mm | 561 mm | 577 mm | 599 mm | 617 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 407 mm |
| Top Tube Length | 533 mm | 546 mm | 555 mm | 578 mm | 593 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 470 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 143 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1011 mm | 1021 mm | 1031 mm | 1042 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
ABLE Force AXS is an Allied Able model. 28 bikes variations carry this model name so far. Take a sneak peek at all Allied Able bikes models from 2021, by clicking here.
Model range prices
The most economical model, the Allied ABLE GRX 810 2021 has a starting price of 6320$. Allied ABLE Red AXS 2021 on the other hand is the most expensive at 10155$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2021 and its price was 7925$. If we compare this with the average Gravel bike cost we notice that the price is 221.89% higher.
ABLE Force AXS components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Allied ABLE Force AXS 2021, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The ABLE Force AXS has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Allied ABLE Force AXS bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
