Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GX Eagle AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS
Shift Levers
SRAM Rival ETap AXS HRD
Cassette
SRAM Eagle XG-1275 10-50
Crank
SRAM Rival 1 D1 Dub
Bottom Bracket
SRAM DUB Threaded
Chain
SRAM GX Eagle
Wheels
Rims
Industry Nine 1/1 GRCX
Tires
WTB Resolute SG2 700x42
Brakes
Brakes
SRAM Rival AXS Hydraulic w/160mm G3 CL Rotors
Cockpit
Stem
FSA Energy SCR
Handlebar
FSA Adventure Compact Alloy
Seat
Saddle
Selle Italia Model X
Seatpost
FSA Energy Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.46 mm | 1.48 mm | 1.51 mm | 1.52 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 599 mm | 609 mm | 619 mm | 630 mm | 645 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 77 mm | 65 mm | 66 mm | 72 mm | 72 mm |
| Stack | 535 mm | 561 mm | 577 mm | 599 mm | 617 mm |
| Reach | 378 mm | 384 mm | 389 mm | 398 mm | 407 mm |
| Top Tube Length | 533 mm | 546 mm | 555 mm | 578 mm | 593 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 73.25 ° | 73.25 ° |
| Seat Tube Length | 470 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 143 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1011 mm | 1021 mm | 1031 mm | 1042 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 782 mm | 802 mm | 822 mm | 842 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
ABLE SRAM Rival AXS belongs to the Allied Able model. 28 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Allied ABLE SRAM Rival AXS 2023 is the most economical model, with a starting price of 6410$. Allied ABLE SRAM Red AXS 2023 on the other hand costs 10120$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 6410$. Comparing this to the average Gravel bike price, we see that the price is 160.36% more expensive.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The ABLE SRAM Rival AXS 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The ABLE SRAM Rival AXS has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
