Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM Red AXS
Front Derailleur
SRAM Red AXS
Shift Levers
SRAM Red AXS
Cassette
SRAM Red XG-1290 D1 10-33
Crank
SRAM Red 48/35
Bottom Bracket
SRAM DUB
Chain
SRAM Red
Wheels
Rims
Industry Nine i9.35 Carbon Wheelset - XDR
Tires
Vittoria Corsa Control Tubeless TLR Tire - 700x28
Brakes
Brakes
SRAM Red HRD
Cockpit
Stem
FSA K-Force Light 2.0 Stem
Handlebar
FSA K-Force Compact Carbon Handlebar
Seat
Saddle
Ergon SR10 Sport
Seatpost
FSA K-Force Light Carbon Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.31 mm | 1.36 mm | 1.39 mm | 1.42 mm | 1.46 mm | 1.49 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 267 mm | 267 mm | 268 mm | 268 mm |
| Front Center | 570 mm | 575 mm | 581 mm | 592 mm | 607 mm | 614 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 62 mm | 58 mm | 60 mm | 55 mm | 55 mm | 51 mm |
| Stack | 498 mm | 520 mm | 536 mm | 557 mm | 585 mm | 605 mm |
| Reach | 379 mm | 383 mm | 386 mm | 393 mm | 401 mm | 407 mm |
| Top Tube Length | 510 mm | 534 mm | 545 mm | 562 mm | 580 mm | 598 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.25 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 482 mm | 512 mm | 532 mm | 552 mm | 572 mm | 602 mm |
| Head Tube Angle | 72.25 ° | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Head Tube Length | 97 mm | 117 mm | 137 mm | 157 mm | 187 mm | 207 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 966 mm | 971 mm | 978 mm | 989 mm | 1005 mm | 1012 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 69 mm | 69 mm | 67 mm | 67 mm |
| Standover Height | 747 mm | 772 mm | 788 mm | 812 mm | 836 mm | 859 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm |
| Rider Max Height | 163 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
Alfa Disc Red AXS is part of the Allied Alfa model. Allied released 38 bikes variations of this model so far. Take a sneak peek at all Allied Alfa bikes models from 2023, by clicking here.
Model range prices
Allied Alfa Disc Ultegra 8020 Mechanical 2023 is the most affordable bike of this model and has a price of 6720$. On the other hand, Allied ALFA Dura-Ace R9200 Di2 2023, is the most expensive and costs 11770$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Endurance bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Allied Alfa Disc Red AXS price was 10710$. If we compare this with the average Endurance bike cost we notice that the price is 356.52% higher.
Alfa Disc Red AXS components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Allied Alfa Disc Red AXS 2023, has a 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Alfa Disc Red AXS has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 6 sizes. They vary from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
