Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED eTAP, X01 Eagle AXS -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
155cm - 163cm
49cm
155cm - 163cm
52cm
161cm - 169cm
52cm
161cm - 169cm
54cm
166cm - 175cm
54cm
166cm - 175cm
56cm
172cm - 181cm
56cm
172cm - 181cm
58cm
178cm - 186cm
58cm
178cm - 186cm
61cm
183cm - 191cm
61cm
183cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
carbon
Drivetrain
Rear Derailleur
SRAM ETAP AXS
Front Derailleur
SRAM ETAP AXS
Shift Levers
SRAM ETAP AXS
Cassette
10-33
Crank
SRAM RED 50x37
Chain
SRAM ETAP AXS
Wheels
Rims
MAVIC COSMIC UST
Cockpit
Stem
ZIPP SERVICE COURSE
Handlebar
ZIPP SERVICE COURSE
Seat
Saddle
Fabric Scoop
Seatpost
ZIPP SERVICE COURSE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 49cm | 52cm | 52cm | 54cm | 54cm | 56cm | 56cm | 58cm | 58cm | 61cm | 61cm |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.39 mm | 1.36 mm | 1.43 mm | 1.39 mm | 1.47 mm | 1.43 mm | 1.49 mm | 1.47 mm | 1.54 mm | 1.5 mm | 1.54 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 280 mm | 280 mm | 280 mm | 280 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 575 mm | 575 mm | 580 mm | 580 mm | 587 mm | 587 mm | 597 mm | 597 mm | 612 mm | 612 mm | 619 mm | 619 mm |
| Rake | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Trail | 63 mm | 63 mm | 54 mm | 54 mm | 55 mm | 53 mm | 54 mm | 54 mm | 50 mm | 50 mm | 51 mm | 57 mm |
| Stack | 500 mm | 517 mm | 521 mm | 539 mm | 536 mm | 556 mm | 559 mm | 576 mm | 586 mm | 604 mm | 607 mm | 625 mm |
| Reach | 377 mm | 371 mm | 382 mm | 376 mm | 385 mm | 377 mm | 391 mm | 386 mm | 398 mm | 393 mm | 405 mm | 405 mm |
| Top Tube Length | 510 mm | 510 mm | 534 mm | 534 mm | 545 mm | 545 mm | 562 mm | 562 mm | 580 mm | 580 mm | 598 mm | 598 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 74 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 72.3 ° | 72.3 ° |
| Seat Tube Length | 482 mm | 482 mm | 512 mm | 512 mm | 532 mm | 532 mm | 552 mm | 552 mm | 572 mm | 572 mm | 602 mm | 602 mm |
| Head Tube Angle | 72 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73.3 ° | 73.3 ° | 73.5 ° | 73.5 ° | 73.8 ° | 73.8 ° |
| Head Tube Length | 97 mm | 117 mm | 117 mm | 137 mm | 137 mm | 157 mm | 157 mm | 177 mm | 187 mm | 207 mm | 207 mm | 227 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 981 mm | 981 mm | 986 mm | 986 mm | 994 mm | 994 mm | 1004 mm | 1004 mm | 1020 mm | 1020 mm | 1027 mm | 1027 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 69 mm | 69 mm | 69 mm | 69 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 747 mm | 747 mm | 772 mm | 772 mm | 788 mm | 788 mm | 812 mm | 812 mm | 836 mm | 836 mm | mm | mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 155 cm | 161 cm | 161 cm | 166 cm | 166 cm | 172 cm | 172 cm | 178 cm | 178 cm | 183 cm | 183 cm |
| Rider Max Height | 163 cm | 163 cm | 169 cm | 169 cm | 175 cm | 175 cm | 181 cm | 181 cm | 186 cm | 186 cm | 191 cm | 191 cm |
About this model
ALLROAD SRAM RED AXS is part of the Allied Allroad model. 34 bikes variations carry this model name so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Allied ALLROAD Shimano Ultegra 2020 has a starting price of 5799$. Allied ALLROAD SRAM RED AXS 2020 on the other hand is the most expensive at 8999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2020 and its price was 8999$. Comparing the average cost of a Gravel bike to this one, you will see that ALLROAD SRAM RED AXS price is 265.52% higher.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The ALLROAD SRAM RED AXS 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Allied ALLROAD SRAM RED AXS is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 12 sizes. They vary from 155 cm – 191 cm (5.09 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
