Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" / 27.5" -
Travel Front 170mm -
Travel Rear 170mm -
Fork Fox
-
Groupset XX1 Eagle AXS, e*thirteen -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano STEPS system -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX FLOAT 38, Kashima coating, GRIP2 damper, 42mm offset
Rear Shock
FOX FLOAT X2, Kashima coating, 230mm x 65mm
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS, 12-speed, electronic wireless
Front Derailleur
None
Shift Levers
SRAM XX1 Eagle AXS Controller, 12-speed, electronic wireless
Cassette
SRAM XX1 Eagle XG-1299, 12-speed, 10-52 tooth, Rainbow finish
Crank
e*thirteen EP8, carbon, 165mm length
Chain
SRAM XX1 Eagle, 12-speed, Rainbow finish
Chain Guide
e*thirteen EP8
Pedals
None
Wheels
Front Hub
DT Swiss HXC wheelset, 15x110mm Boost front, 12x148mm Boost rear with XD driver
Rear Hub
DT Swiss HXC wheelset, 15x110mm Boost front, 12x148mm Boost rear with XD driver
Rims
DT Swiss HXC Carbon wheelset, 30mm width
Spokes
DT Swiss HXC wheelset
Tires
Front: Maxxis Minion DHF, 29" x 2.5", Rear: Maxxis Minion DHR II, 27.5" x 2.6"
Brakes
Brakes
SRAM Code RSC, 4-piston, 200mm rotors
Brake Levers
SRAM Code RSC
Cockpit
Stem
TwinWorks, CNC alloy, 35mm, 5° rise
Handlebar
SQlab 30X Carbon high, 12° backsweep
Grips
SQlab 70X medium
Headset
ACROS
Seat
Saddle
SQlab 60X
Seatpost
BikeYoke Revive dropper
Motor & Battery
Motor
Shimano STEPS EP8
Battery
Shimano STEPS system
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.3 mm |
| Bottom Bracket Height | 353 mm | 353 mm |
| Stack | 614 mm | 624 mm |
| Reach | 451 mm | 481 mm |
| Top Tube Length | 597 mm | 626 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° |
| Seat Tube Length | 435 mm | 450 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 120 mm |
| Chainstay Length | 429 mm | 429 mm |
| Wheelbase | 1215 mm | 1245 mm |
| Standover Height | 719 mm | 724 mm |
| Wheels | 29" | 29" |
Model Overview
eFanes 6.0 CNC is an Alutech E Efanes model. 2 e-bikes variations carry this model name so far. Take a sneak peek at all Alutech E Efanes e-bikes models from 2021, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Enduro e-bikes average price
If you want an acceptable Enduro e-bike you should know that the average price is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Enduro e-bikes average weight
The average weight for Enduro e-bikes is 23.42 kg (51.63 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
eFanes 6.0 CNC weighs 21.15 kg (46.63 lbs) and is considerably lighter than the average. In short, the average Enduro e-bike weight is 10.73% higher than this one.
eFanes 6.0 CNC components
Fork
Alutech eFanes 6.0 CNC 2021 e-bike is equipped with the Fox fork, and has 170mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this e-bike is FOX FLOAT X2, with a travel distance of 170mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
The eFanes 6.0 CNC 2021 e-bike is equipped with 29″ carbon wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
Alutech eFanes 6.0 CNC comes with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
