Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset GRX Di2, GRX 800 -
Suspension Rigid -
Drivetrain Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aquila CX-G
Drivetrain
Rear Derailleur
RD-RX815-R, GRX Di2
Front Derailleur
FD-RX815-F, GRX Di2
Shift Levers
ST-RX815, GRX Hydraulic W/SM-BH90 Calipers
Cassette
ICSHG800 11-34T
Crank
IFCRX8102DX81 48-31T
Bottom Bracket
SM-BB72
Chain
ICNHG70111116Q
Wheels
Rims
Mavic Allroad Pro Carbon SL UST Disc
Tires
Hutchinson Overide
Brakes
Brakes
hydraulicDisc
Disk Rotors
SM-RT800, 160mm / 140mm
Cockpit
Stem
3T ARX
Handlebar
PRO Discover
Headset
Aquila
Seat
Saddle
Prologo Dimension Ti-Rox
Seatpost
3T Zero25 / 27.2 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.49 mm | 1.5 mm | 1.55 mm | 1.32 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 173 mm | 178 mm | 183 mm | 188 mm | 197 mm |
| Rake | -356 mm | -354 mm | -354 mm | -354 mm | -325 mm |
| Trail | 501 mm | 495 mm | 490 mm | 486 mm | 455 mm |
| Stack | 541 mm | 562 mm | 573 mm | 594 mm | 514 mm |
| Reach | 376 mm | 376 mm | 381 mm | 384 mm | 388 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 594 mm | 600 mm | 605 mm | 611 mm | 620 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
CX-G 1 is part of the Aquila Cx G model. There are 15 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
The most economical model, the Aquila CX-G Al 2022 has a starting price of 1590$. Aquila CX-G 1 2022 on the other hand is the most expensive at 5784$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2022 for 5784$. In conclusion, this bike price is 134.93% more expensive than the price of the average Gravel bike.
CX-G 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The wheels on CX-G 1 are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CX-G 1 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
