Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aquila CX-G
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400
Front Derailleur
Shimano GRX FD-RX400
Shift Levers
Shimano GRX ST-RX400
Cassette
Shimano CS-HG500-10 Speed 11-34T
Crank
Shimano FC-RX600-10 speed 48-31T
Bottom Bracket
Shimano BB-RS500-PB
Chain
Shimano CN-HG54 10 Speed
Wheels
Rims
Shimano WH-R170
Tires
Hutchinson Overide 700x38
Brakes
Disk Rotors
Shimano, 160mm / 140mm
Cockpit
Stem
Alloy
Handlebar
Alloy
Headset
Aquila
Seat
Saddle
Selle Italia Boost X3
Seatpost
Carbon / 27.2 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.49 mm | 1.5 mm | 1.55 mm | 1.32 mm |
| Bottom Bracket Height | 282 mm | 282 mm | 282 mm | 282 mm | 282 mm |
| Front Center | 173 mm | 178 mm | 183 mm | 188 mm | 197 mm |
| Rake | -356 mm | -354 mm | -354 mm | -354 mm | -325 mm |
| Trail | 501 mm | 495 mm | 490 mm | 486 mm | 455 mm |
| Stack | 541 mm | 562 mm | 573 mm | 594 mm | 514 mm |
| Reach | 376 mm | 376 mm | 381 mm | 384 mm | 388 mm |
| Top Tube Length | 525 mm | 540 mm | 555 mm | 570 mm | 585 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° |
| Head Tube Length | 120 mm | 140 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 594 mm | 600 mm | 605 mm | 611 mm | 620 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
CX-G Tiagra belongs to the Aquila Cx G model. 15 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Aquila CX-G Al 2021 is the most economical model, with a starting price of 1590$. Aquila CX-G GRX Di2 2021 on the other hand costs 5965$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Aquila CX-G Tiagra price was 2313$. Comparing the average cost of a Gravel bike to this one, you will see that CX-G Tiagra price is 6.44% lower.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Aquila CX-G Tiagra 2021, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The CX-G Tiagra has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
