Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Suspension Rigid -
Brakes Rim
Sizing
Recommended size guide.
53cm
165cm - 175cm
55cm
175cm - 185cm
60cm
195cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aquila Uno
Drivetrain
Crank
Realspeed TRK1 144BCD
Bottom Bracket
Realspeed External
Chain
KMC Z410RB
Wheels
Rims
Realspeed Radium 30
Tires
Hutchinson Epsilon 700x23
Brakes
Brakes
Rim
Cockpit
Stem
Realspeed RS10
Handlebar
Realspeed Alloy
Headset
Token
Seat
Saddle
Post
Seatpost
Aquila 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 51cm | 53cm | 55cm | 57cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.28 mm | 1.27 mm | 1.29 mm | 1.31 mm | 1.31 mm | 1.35 mm |
| Bottom Bracket Height | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm | 281 mm |
| Front Center | 572 mm | 576 mm | 578 mm | 586 mm | 598 mm | 609 mm |
| Rake | 85 mm | 58 mm | 58 mm | 52 mm | 50 mm | 51 mm |
| Stack | 466 mm | 471 mm | 494.9 mm | 509.2 mm | 523.6 mm | 543.4 mm |
| Reach | 363.8 mm | 371.9 mm | 383.3 mm | 389.2 mm | 398.9 mm | 403.7 mm |
| Top Tube Length | 490 mm | 507 mm | 527 mm | 537 mm | 552 mm | 562 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 75.3 ° | 72.6 ° | 74.5 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 130 mm | 144.7 mm | 165 mm |
| Chainstay Length | 382 mm | 382 mm | 382 mm | 382 mm | 382 mm | 382 mm |
| Wheelbase | 947 mm | 951 mm | 953 mm | 961 mm | 974 mm | 984 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 154 cm | cm | 175 cm | 185 cm | 195 cm | 200 cm |
Model Overview
Equipe UNO is part of the Aquila Equipe model. Aquila released 38 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Aquila Equipe UNO 2023 is the most economical model, with a starting price of 1247$. Aquila Equipe EVO R – Dura-ace Di2 R9270 Di2 2023 on the other hand costs 10151$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even though the average price of a Race bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1247$. Comparing this to the average Race bike price, we see that the price is 168.64% smaller.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When leaving the production line, the Equipe UNO model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they are not nearly as effective as hydraulic brakes are.
