arc8 Escapee DB FORCE eTAP AXS 2022
2022 Road
Estimate price |
7,282$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTap -
Suspension Rigid -
Battery SRAM Powerpack / inkl. Ladegeräte -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
51cm
170cm - 176cm
54cm
175cm - 181cm
57cm
180cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ARC8 Escapee DB, Carbon
Suspension Fork
ARC8 Escapee DB, Carbon
Drivetrain
Rear Derailleur
SRAM Force eTap AXS
Front Derailleur
SRAM Force eTap AXS
Shift Levers
SRAM Force eTap AXS
Cassette
SRAM XG1270 10-33
Crank
SRAM Force 48/35
Bottom Bracket
SRAM BSA
Chain
SRAM Force
Wheels
Rims
Front: ARC8 Carbon 50mm od. 38 mm & ZIPP 76/176 & Pillar Aero, Rear: ARC8 Carbon 50mm od. 38 mm & ZIPP 76/176 & Pillar Aero
Tires
Front: Wolfpack Road Race 28 mm, Rear: Wolfpack Road Race 28 mm
Brakes
Brakes
SRAM Force eTap AXS
Cockpit
Stem
ICH Stem
Handlebar
Alu Lenker (Carbon Lenker + 160 €)
Headset
ARC8
Seat
Saddle
Selle San Marco Monza
Seatpost
ARC8 SP Carbon 15mm Setback, 400mm lang
Motor & Battery
Battery
SRAM Powerpack / inkl. Ladegeräte
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 57cm | 60cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.41 mm | 1.42 mm | 1.42 mm | 1.43 mm |
| Bottom Bracket Height | 265 mm | 265 mm | 265 mm | 265 mm | 265 mm |
| Front Center | 568 mm | 587 mm | 591 mm | 608 mm | 626 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 66 mm | 42 mm | 56 mm | 57 mm | 58 mm |
| Stack | 510 mm | 527 mm | 546 mm | 565 mm | 585 mm |
| Reach | 362 mm | 374 mm | 385 mm | 398 mm | 410 mm |
| Top Tube Length | 511 mm | 528 mm | 545.5 mm | 563.5 mm | 581 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 422 mm | 453 mm | 477 mm | 499 mm | 521 mm |
| Head Tube Angle | 70.5 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 103 mm | 116 mm | 135 mm | 156 mm | 176 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 407 mm |
| Wheelbase | 964 mm | 983 mm | 987 mm | 1005 mm | 1023 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 71 mm | 71 mm | 71 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Escapee DB FORCE eTAP AXS is an Arc8 Escapee model. ARC8 released 9 bikes variations of this model so far. Take a sneak peek at all Arc8 Escapee bikes models from 2022, by clicking here.
Model range prices
ARC8 Escapee DB 105 DB 2022 is the most affordable bike of this model and has a price of 5096$. On the other hand, ARC8 Escapee DB DURA ACE DI2 2022, is the most expensive and costs 8281$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Race bikes
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 6741$. Comparing the average cost of a Race bike to this one, you will see that Escapee DB FORCE eTAP AXS price is 101.22% more expensive.
Escapee DB FORCE eTAP AXS components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The wheels on Escapee DB FORCE eTAP AXS are the 700c carbon type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Escapee DB FORCE eTAP AXS comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
