Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
160cm - 179cm
LG
177cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ARC8 Essential, Size M, L, Carbon V & H
Suspension Fork
Fox 34 Float Performance 140mm Grip
Rear Shock
Fox Float X Performance
Drivetrain
Rear Derailleur
Shimano XT RD-M8100 / SGS / 12-spd / Shadow+
Shift Levers
Shimano XT SL-M8100
Cassette
Shimano XT CS-M8100 / 12-spd / 10-51T
Crank
Shimano XT FC-M8120 30T o. 32T / 12-spd / 170mm
Bottom Bracket
Shimano BB-MT800 / BSA
Chain
Shimano XT CN-M8100 / 12-spd
Wheels
Rims
Front: NEWMEN Wheel Evolution A.30 29" 15x110 SP, Rear: NEWMEN Wheel Evolution A.30 29" 12x148 SP
Tires
Front: Wolfpack Trail 29x2,4, Rear: Wolfpack Trail 29x2,4
Brakes
Brakes
Shimano XT Disc BR-M8120 4-Piston / BL-M8100 Lever
Cockpit
Stem
Faserwerk Baslerstab 35mm o. 50mm
Handlebar
Faserwek Baslerstab
Grips
Faserwerk Handschmeichler
Headset
Acros
Seat
Saddle
Selle San Marco Dirty Ed
Seatpost
BikeYoke Revive 160mm o. 185mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.33 mm | 1.27 mm |
| Bottom Bracket Height | 334 mm | 334 mm |
| Front Center | 795 mm | 832 mm |
| Rake | 44 mm | 44 mm |
| Trail | 134 mm | 134 mm |
| Stack | 608 mm | 621 mm |
| Reach | 458 mm | 488 mm |
| Top Tube Length | 589 mm | 645 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 410 mm | 440 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 115 mm |
| Chainstay Length | 423 mm | 423 mm |
| Wheelbase | 1215 mm | 1252 mm |
| Bottom Bracket Drop | 40 mm | 40 mm |
| Standover Height | 695 mm | 697 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 160 cm | 177 cm |
| Rider Max Height | 179 cm | 190 cm |
Model Overview
ESSENTIAL XT belongs to the Arc8 Essential model. 6 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
ARC8 ESSENTIAL SLX 2022 is the most affordable bike of this model and has a price of 4883$. On the other hand, ARC8 ESSENTIAL XT 2022, is the most expensive and costs 5626$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2022 and its price was 5626$. In conclusion, this bike price is 103.69% higher than the price of the average Trail bike.
Overview of components
Fork
The ESSENTIAL XT comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The ESSENTIAL XT has a rear shock with a travel of 130mm. The model Fox Float X Performance is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The ESSENTIAL XT 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 2 sizes. They vary from 160 cm – 190 cm (5.25 ft – 6.23 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the ESSENTIAL XT. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
