Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox ZEB
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
173cm - 183cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ARC8 EXTRA, S-M-L size, Carbon V & H
Suspension Fork
Rock Shox ZEB, 170mm
Rear Shock
Rock Shox SuperDeluxe Ultimate
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100 / SGS / 12-spd / Shadow+
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 / 12-spd / 10-51T
Crank
Shimano SLX FC-M7120 32T / 12-spd / 175mm
Bottom Bracket
Shimano BB-MT800 / BSA
Chain
Shimano SLX CN-M7100 / 12-spd
Wheels
Rims
Front: Newmen Performance 30, Rear: Newmen Performance 30
Tires
Front: Wolfpack Enduro 29x2,4, Rear: Wolfpack Enduro 29x2,4
Brakes
Brakes
Shimano SLX Disc BR-M7120 4-Piston / BL-M7100 Lever
Cockpit
Stem
Newmen Evolution SL 40mm
Handlebar
Faserwerk Rockstock 800mm Carbon
Grips
ARC8
Headset
Acros
Seat
Saddle
Selle San Marco Dirty Ed
Seatpost
RaceFace Aeffect incl. EV Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.32 mm | 1.27 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 771 mm | 800 mm | 829 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 131 mm | 131 mm | 133 mm |
| Stack | 599 mm | 608 mm | 617 mm |
| Reach | 437 mm | 462 mm | 487 mm |
| Top Tube Length | 557 mm | 614 mm | 642 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 380 mm | 400 mm | 440 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1196 mm | 1225 mm | 1254 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 684 mm | 686 mm | 684 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 173 cm | 181 cm |
| Rider Max Height | 170 cm | 183 cm | cm |
Model Overview
EXTRA SLX belongs to the Arc8 Extra model. 7 bikes variations carry this model name so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
ARC8 EXTRA SLX 2022 is the most affordable bike of this model and has a price of 5308$. On the other hand, ARC8 EXTRA XT 2022, is the most expensive and costs 6476$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want an acceptable Enduro bike you should know that the average price is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5308$. Doing a quick comparison, we notice that EXTRA SLX price is 47.49% more expensive than the average cost of an Enduro bike.
Overview of components
Fork
The RockShox ZEB is included from the factory. It has a travel distance of 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the Rock Shox SuperDeluxe Ultimate rear shock model, which has a travel of 160mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The EXTRA SLX 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. ARC8 EXTRA SLX is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Dropper post
ARC8 EXTRA SLX includes a dropper post. Therefore, climbing or descending will be a breeze.
