Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Rival 1 -
Suspension Rigid -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Dark Matter
Suspension Fork
Dark Matter specific
Drivetrain
Rear Derailleur
SRAM Rival 1 Long Cage
Shift Levers
SRAM Rival 1
Cassette
SRAM PG 1130 11/42
Bottom Bracket
SRAM GXP BB86 86.5/WA91.5
Chain
KMC X11 EPT
Wheels
Rims
48mm
Tires
Challenge Gravel Grinder Tubeless 700x38c
Brakes
Brakes
SRAM Rival
Brake Levers
SRAM Rival 1
Disk Rotors
SRAM PaceLine Centerlock FR: 160mm RR: 140mm
Cockpit
Handlebar
Prologo Plaintouch Black
Headset
FSA NO.30/Kit + 3D+ w/ TH881-1
Seat
Saddle
Prologo AKERO STN
Seatpost
Argon 18 TDS-C Carbon, 27.2mm (included with frameset)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 53cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.51 mm | 1.52 mm | 1.53 mm | 1.56 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 590 mm | 593 mm | 606 mm | 612 mm | 628 mm | 641 mm |
| Rake | 54 mm | 53 mm | 54 mm | 49 mm | 49 mm | 49 mm |
| Trail | 73 mm | 64 mm | 60 mm | 62 mm | 62 mm | 59 mm |
| Stack | 533 mm | 553 mm | 573 mm | 593 mm | 613 mm | 638 mm |
| Reach | 359 mm | 370 mm | 380 mm | 390 mm | 400 mm | 410 mm |
| Top Tube Length | 495 mm | 516 mm | 537 mm | 559 mm | 582 mm | 606 mm |
| Seat Tube Angle | 75.5 ° | 74.9 ° | 74.3 ° | 73.7 ° | 73.1 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 485 mm | 520 mm | 555 mm | 590 mm |
| Head Tube Angle | 69.5 ° | 71 ° | 71.4 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 154 mm | 171 mm | 192 mm | 216 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1011 mm | 1014 mm | 1027 mm | 1033 mm | 1049 mm | 1062 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 704 mm | 732 mm | 763 mm | 794 mm | 824 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Dark Matter SRAM Rival 1 belongs to the Argon18 Dark model. There are 15 bikes that carry this model name. Take a sneak peek at all Argon18 Dark bikes models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Dark Matter SRAM Rival 1 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Dark Matter SRAM Rival 1 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Dark Matter SRAM Rival 1 has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
