Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Rival 1 -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Subito Gravel
Suspension Fork
Subito Gravel specific
Drivetrain
Rear Derailleur
SRAM Rival 1 Long Cage
Front Derailleur
-
Shift Levers
SRAM Rival 1 HRD
Cassette
SRAM PowerGlide 1130 11-42
Bottom Bracket
SRAM PFGXP Road 86.5/WA91.5
Chain
KMC X11 EPT
Wheels
Rims
FSA NS AGX i21 with Ebikemotion Motor
Tires
Vittoria Terreno Dry G2.0 TLR 650x47c
Brakes
Brakes
SRAM Rival
Brake Levers
SRAM Rival 1 HRD
Disk Rotors
SRAM G2 CleanSweep Rotor / F:160mm R:160mm
Cockpit
Handlebar
Ciclovation LEATHER TOUCH Tornado Reflective
Headset
FSA 30 with 3D+
Seat
Saddle
Repente Quasar
Seatpost
Argon 18 TDS-C
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 53cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Front Center | 584 mm | 587 mm | 599 mm | 603 mm | 621 mm | 637 mm |
| Rake | 56 mm | 55 mm | 55 mm | 49 mm | 49 mm | 50 mm |
| Trail | 65 mm | 57 mm | 54 mm | 56 mm | 56 mm | 53 mm |
| Stack | 523 mm | 543 mm | 565 mm | 588 mm | 612 mm | 638 mm |
| Reach | 354 mm | 365 mm | 375 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 488 mm | 508 mm | 530 mm | 553 mm | 576 mm | 601 mm |
| Seat Tube Angle | 75.5 ° | 74.9 ° | 74.3 ° | 73.7 ° | 73.1 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 485 mm | 520 mm | 555 mm | 590 mm |
| Head Tube Angle | 69.3 ° | 70.8 ° | 71.3 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 108 mm | 124 mm | 145 mm | 163 mm | 188 mm | 215 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 997 mm | 1000 mm | 1013 mm | 1017 mm | 1035 mm | 1051 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 686 mm | 713 mm | 745 mm | 776 mm | 807 mm | 838 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
About this model
Subito E-Gravel SRAM Rival 1 is part of the Argon18 E Subito model. There are 11 e-bikes that carry this model name. Take a sneak peek at all Argon18 E Subito e-bikes models from 2022, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel e-bikes
Our math shows that the average cost of a dependable Gravel e-bike is 3642$. However, you could also get a good Gravel e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Subito E-Gravel SRAM Rival 1 components
Fork material
Subito E-Gravel SRAM Rival 1 has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When leaving the production line, the Subito E-Gravel SRAM Rival 1 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Argon 18 Subito E-Gravel SRAM Rival 1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
