Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 700c -
Groupset Rival 22 -
Suspension Rigid -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Subito Road
Suspension Fork
Subito Road specific
Drivetrain
Rear Derailleur
SRAM Rival 22 MAX 11-32CS WIFLI
Front Derailleur
SRAM Rival 22 YAW With Chain Spotter
Shift Levers
SRAM Rival 22 HRD
Cassette
SRAM PG 1130 11/32
Bottom Bracket
SRAM PFGXP Road 86.5/WA91.5
Chain
KMC X11 EPT
Wheels
Rims
Vision Team 30 with Ebikemotion Motor
Tires
Vittoria Zaffiro 700x30c
Brakes
Brakes
SRAM Rival
Brake Levers
SRAM Rival 22 HRD
Disk Rotors
SRAM G2 CleanSweep Rotor / F:160mm R:160mm
Cockpit
Handlebar
Ciclovation LEATHER TOUCH Tornado Reflective
Headset
FSA 30 with 3D+
Seat
Saddle
Repente Quasar
Seatpost
Argon 18 TDS-C
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 50cm | 53cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 584 mm | 587 mm | 599 mm | 603 mm | 621 mm | 637 mm |
| Rake | 56 mm | 55 mm | 55 mm | 49 mm | 49 mm | 50 mm |
| Trail | 67 mm | 59 mm | 56 mm | 58 mm | 58 mm | 55 mm |
| Stack | 523 mm | 543 mm | 565 mm | 588 mm | 612 mm | 638 mm |
| Reach | 354 mm | 365 mm | 375 mm | 385 mm | 395 mm | 405 mm |
| Top Tube Length | 488 mm | 508 mm | 530 mm | 553 mm | 576 mm | 601 mm |
| Seat Tube Angle | 75.5 ° | 74.9 ° | 74.3 ° | 73.7 ° | 73.1 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 485 mm | 520 mm | 555 mm | 590 mm |
| Head Tube Angle | 69.3 ° | 70.8 ° | 71.3 ° | 72 ° | 72 ° | 72.3 ° |
| Head Tube Length | 108 mm | 124 mm | 145 mm | 163 mm | 188 mm | 215 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 997 mm | 1000 mm | 1013 mm | 1017 mm | 1035 mm | 1051 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 686 mm | 713 mm | 745 mm | 776 mm | 807 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Subito E-Road SRAM Rival 22 is an Argon18 E Subito model. There are 11 e-bikes that carry this model name. You can easily view all of the Argon18 E Subito e-bikes models from 2022, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race e-bikes average price
If you want to purchase a solid Race e-bike, it is important to know that the average cost is 4156$. However, you could also get a good Race e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Subito E-Road SRAM Rival 22 components
Fork material
The fork on this e-bike is made out of carbon, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Subito E-Road SRAM Rival 22 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Subito E-Road SRAM Rival 22 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
