Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset XX1 Eagle AXS, e*thirteen XCX -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Argonaut GR3 Frameset
Suspension Fork
GR3 Integrated Disc 1.5" Taper 12x100
Drivetrain
Rear Derailleur
SRAM XX1 Eagle AXS Rear Derailleur - 12 Speed, Black
Front Derailleur
N/A
Cassette
e*thirteen Helix R 12-Speed Cassette, 9-45, Intergalactic
Crank
e*thirteen XCX Race Carbon Gravel Crank
Bottom Bracket
CHRIS KING ThreadFit™ T47-30x
Chain
SRAM XX1 EAGLE AXS CHAIN
Wheels
Rims
See options below
Tires
SCHWALBE G-ONE R, 700x40, Tubeless, Addix Race
Brakes
Brakes
Front: SRAM Red AXS, Rear: SRAM Red AXS
Cockpit
Stem
Argonaut RM3 Fully Integrated, (80mm, 90mm, 100mm, 110mm, 120mm)
Handlebar
SES AR Integrated Compact
Headset
Argonaut
Seat
Saddle
Selle Repente Artax GL
Seatpost
Argonaut SEATPOST, 27.2 X 400, 0 OFFSET
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 51.5cm | 53cm | 54.5cm | 56cm | 57.5cm | 59cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.47 mm | 1.49 mm | 1.49 mm | 1.47 mm | 1.54 mm | 1.57 mm |
| Bottom Bracket Height | 272 mm | 272 mm | 274 mm | 274 mm | 274 mm | 276 mm | 276 mm |
| Rake | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm | 57 mm |
| Stack | 520 mm | 538.6 mm | 555.2 mm | 564.5 mm | 573.8 mm | 606.8 mm | 630.1 mm |
| Reach | 357 mm | 366.7 mm | 371.6 mm | 378.4 mm | 390.6 mm | 393.3 mm | 401.1 mm |
| Top Tube Length | 508.1 mm | 523.1 mm | 538.1 mm | 553.1 mm | 568.1 mm | 583.1 mm | 598.1 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 427.1 mm | 428 mm | 445.6 mm | 469 mm | 477.5 mm | 519.2 mm | 541.2 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm | 170 mm | 205 mm | 230 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Bottom Bracket Drop | 77 mm | 77 mm | 75 mm | 75 mm | 75 mm | 73 mm | 73 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
GR3 RED is part of the Argonaut Gr3 model. Argonaut released 8 bikes variations of this model so far. Take a sneak peek at all Argonaut Gr3 bikes models from 2023, by clicking here.
Model range prices
Argonaut GR3 Ekar 2023 is the cheapest bike model and costs 9700$. Argonaut GR3 RED 2023 is the most expensive one and costs 11500$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 11500$. Comparing this to the average Gravel bike price, we see that the price is 367.1% higher.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
The GR3 RED 2023 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Argonaut GR3 RED is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
