Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork RST VIV AIR
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
155cm - 172cm
19"
170cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted alloy 6061 29" (ASL)
Suspension Fork
RST Viv Air TnL air, lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Front Derailleur
SHIMANO Deore (31.8)
Shift Levers
SHIMANO Deore (30)
Cassette
SHIMANO HG50-10, 11-36 (10)
Crank
SHIMANO Deore, 44-32-24 teeth, 170 / 175 mm cranks
Chain
KMC X10
Pedals
AUTHOR Non Slip alloy
Wheels
Front Hub
AUTHOR Radon, 32 holes
Rear Hub
AUTHOR Radon, 32 holes
Rims
AUTHOR Xenon 29, 32 holes
Spokes
black stainless steel 2.0 mm
Tires
AUTHOR Speed Master 29" × 1.75"
Brakes
Brakes
TEKTRO HD-T530, disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm, 660 / 680 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Area Gel
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" |
|---|---|---|
| Front Center | 634 mm | 655 mm |
| Rake | 44 mm | 44 mm |
| Top Tube Length | 570 mm | 590 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° |
| Head Tube Length | 120 mm | 130 mm |
| Chainstay Length | 450 mm | 450 mm |
| Wheelbase | 1077 mm | 1098 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Wheels | 29" | 29" |
| Rider Min Height | 155 cm | 170 cm |
| Rider Max Height | 172 cm | 185 cm |
About this model
Airline ASL is part of the Author Airline model. 16 bikes variations carry this model name so far. Take a sneak peek at all Author Airline bikes models from 2024, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Hybrid bikes
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Hybrid bikes average weight
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
slightly lighter than average, Airline ASL has a weight of 13.3 kg (29.32 lbs). In other words, this model is 4.14% lighter than the average Hybrid bike.
Airline ASL components
Fork
The RST VIV AIR is included from the factory. It has a travel distance of 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
When leaving the production line, the Airline ASL model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Airline ASL has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 2 sizes. They vary from 155 cm – 185 cm (5.09 ft – 6.07 ft). In conclusion, you won’t have a problem finding one that suits you.
