Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST VOGUE
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 167cm
18"
164cm - 177cm
20"
174cm - 187cm
22"
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted alloy 6061 700c
Suspension Fork
RST Vogue Air TRL air, remote lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO XT
Front Derailleur
SHIMANO Deore (31.8)
Shift Levers
SHIMANO LX (30)
Cassette
SHIMANO HG50-10 11-36 (10)
Crank
SHIMANO Deore 48-36-26 teeth 170 / 175 mm cranks
Chain
KMC X10-1
Pedals
AUTHOR oneside clipless
Wheels
Front Hub
AUTHOR Xenon 32 holes
Rear Hub
AUTHOR Xenon 32 holes
Rims
AUTHOR Radon Cross 32 holes
Spokes
black stainless steel 2.0 mm
Tires
AUTHOR PANARACER Silk Road Cross kevlar 700 x 42c
Brakes
Brakes
TEKTRO Gemini disc hydraulic (6' rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 660 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Sphere Gel
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 612 mm | 633 mm | 654 mm | 674 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1051 mm | 1072 mm | 1093 mm | 1113 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 167 cm | 177 cm | 187 cm | 200 cm |
About this model
Codex belongs to the Author Codex model. Author released 17 bikes variations of this model so far. Take a sneak peek at all Author Codex bikes models from 2018, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Hybrid bikes average weight
On a deeper look, we notice that the average weight of a Hybrid bike is 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
considerably lighter than average, Codex has a weight of 12.3 kg (27.12 lbs). To sum up, it’s 12.6% lighter than the average weight of Hybrid bikes.
Overview of components
Fork
Author Codex 2018 bike is equipped with the RST VOGUE fork, and has 60mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Codex are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Codex has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
