Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 80mm -
Fork RST VOGUE
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 168cm
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
triple butted alloy 6061 29"
Suspension Fork
RST Vogue Air TRL air remote lock out (80 mm)
Drivetrain
Rear Derailleur
SHIMANO XT
Front Derailleur
SHIMANO Deore (31.8)
Shift Levers
SHIMANO Deore (30)
Cassette
SHIMANO HG50-10 11-36 (10)
Crank
SHIMANO Deore 48-36-26 teeth 170 / 175 mm cranks
Chain
KMC X10
Pedals
AUTHOR alloy
Wheels
Front Hub
AUTHOR Xenon 32 holes
Rear Hub
AUTHOR Xenon 32 holes
Rims
AUTHOR Xenon 29 32 holes
Spokes
stainless steel hi-ten 2.0 mm black
Tires
AUTHOR Speed Master Kevlar 29" x 1.75"
Brakes
Brakes
TEKTRO Gemini disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 660 / 680 mm
Grips
AUTHOR Microtech ErgoGrip
Seat
Saddle
AUTHOR Sphere Gel
Seatpost
AUTHOR alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 612 mm | 633 mm | 654 mm | 674 mm |
| Rake | 68 mm | 68 mm | 68 mm | 68 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 160 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1061 mm | 1082 mm | 1103 mm | 1123 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 150 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 168 cm | 178 cm | 188 cm | 200 cm |
Model Overview
Codex is part of the Author Codex model. Author released 17 bikes variations of this model so far. Take a sneak peek at all Author Codex bikes models from 2020, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
If you want to purchase a solid Hybrid bike, it is important to know that the average cost is 562$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Hybrid bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Hybrid bikes
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Codex weighs 12.5 kg (27.56 lbs) and is considerably lighter than the average. In other words, this model is 10.8% lighter than the average Hybrid bike.
Overview of components
Fork
Author Codex 2020 bike is equipped with the RST VOGUE fork, and has 80mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When it comes to wheels, the Codex bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Codex comes in 4 sizes, that range from 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
