Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NEON
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061
Suspension Fork
RST Neon T (60 mm)
Drivetrain
Rear Derailleur
SHIMANO TY500
Front Derailleur
SHIMANO TY510 (31.8)
Shift Levers
SHIMANO (21)
Cassette
SHIMANO MF-TZ510-7 14-28 (7)
Crank
PROWHEEL 48-38-28 teeth 170 mm cranks
Chain
KMC Z7
Pedals
resin
Wheels
Front Hub
QUANDO 36 holes
Rear Hub
QUANDO 36 holes
Rims
alloy 36 holes
Spokes
steel
Tires
AUTHOR Cross 700 × 38c
Brakes
Brakes
TEKTRO V
Cockpit
Stem
ZOOM alloy
Handlebar
steel 20 mm 660mm
Grips
AUTHOR high density foam
Seat
Saddle
AUTHOR Sphere
Seatpost
ZOOM alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 18" | 20" | 22" |
|---|---|---|---|
| Front Center | 651 mm | 667 mm | 675 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Top Tube Length | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1090 mm | 1106 mm | 1114 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 178 cm | 188 cm | 200 cm |
About this model
Compact belongs to the Author Compact model. There are 11 bikes that carry this model name. You can easily view all of the Author Compact bikes models from 2022, here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Hybrid bikes
If we make a quick analysis of the average weight of a Hybrid bike, we get 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
slightly lighter than average, Compact has a weight of 13.5 kg (29.76 lbs). In other words, this model is 2.59% lighter than the average Hybrid bike.
Compact components
Fork
The RST NEON is included from the factory. It has a travel distance of 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on Compact are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Compact has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
Author Compact bike has 3 sizes, in the range of 165 cm – 200 cm (5.41 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
