Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RST F1RST
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery SHIMANO BT-E8035 Li-lon, 36 V, 14 Ah, 500 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
158cm - 172cm
19"
169cm - 184cm
21"
182cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 27.5"
Suspension Fork
RST F1RST 27.5 15 TRL air 15 mm thru axle remote lock out (120 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Shift Levers
SHIMANO Deore (10)
Cassette
SHIMANO HG50-10 11-36 (10)
Crank
SHIMANO Steps E8000 38 teeth 170 / 175 mm cranks
Bottom Bracket
STEPS, press-fit
Chain
KMC e10T
Pedals
HT platform
Wheels
Front Hub
AUTHOR Helium 15 / Xenon 12 15 × 100 mm thru front axle 12 × 142 mm thru rear axle 32 holes
Rear Hub
AUTHOR Helium 15 / Xenon 12 15 × 100 mm thru front axle 12 × 142 mm thru rear axle 32 holes
Rims
AUTHOR E-Krypton 27.5 32 holes
Spokes
stainless steel hi-ten 2.2 mm black
Tires
VITTORIA Barzo G2.0 kevlar 27.5" × 2.25"
Brakes
Brakes
TRP Slate 4 disc hydraulic (7" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 680 / 700 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR Fenix
Seatpost
AUTHOR alloy (30.9)
Motor & Battery
Motor
SHIMANO Steps DUE-7000, 250 W
Battery
SHIMANO BT-E8035 Li-lon, 36 V, 14 Ah, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.5 mm | 1.44 mm |
| Bottom Bracket Height | 304 mm | 304 mm | 304 mm |
| Front Center | 689 mm | 710 mm | 731 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 98 mm | 98 mm | 97 mm |
| Stack | 624 mm | 634 mm | 638 mm |
| Reach | 407 mm | 424 mm | 442 mm |
| Top Tube Length | 598 mm | 618 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 432 mm | 483 mm | 535 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 135 mm |
| Chainstay Length | 463 mm | 463 mm | 463 mm |
| Wheelbase | 1147 mm | 1168 mm | 1189 mm |
| Bottom Bracket Drop | 51 mm | 51 mm | 51 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 169 cm | 182 cm |
| Rider Max Height | 172 cm | 184 cm | 200 cm |
Model Overview
Elevation ASL 27.5 belongs to the Author E Elevation model. Author launched 7 e-bikes of this model so far. Take a sneak peek at all Author E Elevation e-bikes models from 2020, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Trail e-bikes
If we make a quick analysis of the average weight of a Trail e-bike, we get 23.7 kg (52.25 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 10 kg (22.05 lbs), the Elevation ASL 27.5 model is much lighter than average. To sum up, it’s 137% lighter than the average weight of Trail e-bikes.
Overview of components
Fork
This e-bike has the RST F1RST fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When it comes to wheels, the Elevation ASL 27.5 e-bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the e-bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 158 cm – 200 cm (5.18 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
