Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RST AERIAL
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery SHIMANO E-8035 Li-Ion, 36 V, 14 Ah, 504 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
17"
168cm - 180cm
19"
177cm - 190cm
21"
187cm - 202cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 29" (integrated battery)
Suspension Fork
RST Aerial 110-15 TnL air, lock out 15 mm thru axle boost 1.5" tapered column (100 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Shift Levers
SHIMANO Deore (10)
Cassette
SHIMANO CS-M4100-10 11-46 (10)
Crank
SHIMANO Steps E-5010 38 teeth 170 / 175 mm cranks
Bottom Bracket
STEPS, press-fit
Chain
KMC e10T
Pedals
HT platform
Wheels
Front Hub
QUANDO 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rear Hub
QUANDO 15 × 110 mm thru front axle 12 × 148 mm thru rear axle 32 holes
Rims
AUTHOR E-Krypton 29 32 holes
Spokes
black stainless steel 2.2 mm
Tires
CST Patrol 29" × 2.25"
Brakes
Brakes
TEKTRO Orion disc hydraulic (7" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 700 / 720 mm
Grips
AUTHOR Pro Lock
Seat
Saddle
AUTHOR E-Mode
Seatpost
AUTHOR alloy (30.9)
Motor & Battery
Motor
SHIMANO Steps E-5000, 250 W
Battery
SHIMANO E-8035 Li-Ion, 36 V, 14 Ah, 504 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 17" | 19" | 21" |
|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.52 mm | 1.47 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm |
| Front Center | 696 mm | 717 mm | 737 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 96 mm | 97 mm |
| Stack | 633 mm | 642 mm | 647 mm |
| Reach | 404 mm | 421 mm | 440 mm |
| Top Tube Length | 598 mm | 618 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 120 mm | 130 mm | 135 mm |
| Chainstay Length | 473 mm | 473 mm | 473 mm |
| Wheelbase | 1163 mm | 1184 mm | 1204 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 168 cm | 177 cm | 187 cm |
| Rider Max Height | 180 cm | 190 cm | 202 cm |
About this model
Eleve 29 is an Author E Eleve model. 3 e-bikes variations carry this model name so far. Take a sneak peek at all Author E Eleve e-bikes models from 2022, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry e-bikes
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, even though the average price of a Crosscountry e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry e-bikes
If we make a quick analysis of the average weight of a Crosscountry e-bike, we get 23.21 kg (51.17 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 22.4 kg (49.38 lbs), Author e-bike is slightly lighter than average. To sum up, it’s 3.62% lighter than the average weight of Crosscountry e-bikes.
Overview of components
Fork
This e-bike has the RST AERIAL fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
When leaving the production line, the Eleve 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Eleve 29 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 168 cm – 202 cm (5.51 ft – 6.63 ft). In conclusion, finding one for you shouldn’t be a problem.
