Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 50mm -
Fork Suntour M 3010
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
16"
150cm - 166cm
18"
164cm - 176cm
20"
174cm - 186cm
22"
184cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c
Suspension Fork
SUNTOUR M3010 AL (50 mm)
Drivetrain
Rear Derailleur
SHIMANO Altus
Front Derailleur
SHIMANO TX51 (34.9)
Shift Levers
SHIMANO Altus (21)
Cassette
SHIMANO HG20-7 12-32 (7)
Crank
PROWHEEL 48-38-28 teeth 170 / 175 mm cranks
Chain
KMC Z51
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
alloy 32 holes
Spokes
steel
Tires
AUTHOR Speed Master 700 x 42c
Brakes
Brakes
TEKTRO 855
Cockpit
Stem
ZOOM alloy
Handlebar
steel 20 mm 620 / 640 / 660 mm
Grips
AUTHOR high density foam
Seat
Saddle
AUTHOR Courier
Seatpost
ZOOM alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 607 mm | 619 mm | 632 mm | 653 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 559 mm | 571 mm | 584 mm | 603 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 135 mm | 150 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1049 mm | 1061 mm | 1074 mm | 1095 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 164 cm | 174 cm | 184 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm | 196 cm |
About this model
Horizon belongs to the Author Horizon model. Author released 17 bikes variations of this model so far. Take a sneak peek at all Author Horizon bikes models from 2015, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Hybrid bikes average price
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Hybrid bikes
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Author Horizon it’s weighing 13 kg (28.66 lbs). At this weight, is a bit lighter than average. In other words, this model is 6.54% lighter than the average Hybrid bike.
Horizon components
Fork
This bike has the Suntour M 3010 fork installed. The fork’s travel is 50mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The wheels on Horizon are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 150 cm – 196 cm (4.92 ft – 6.43 ft). In short, you can easily find one that suits you.
