Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NEON
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
16"
150cm - 168cm
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061 700c
Suspension Fork
RST Neon T (60 mm)
Drivetrain
Rear Derailleur
SHIMANO Altus
Front Derailleur
SHIMANO TX51 (31.8)
Shift Levers
SHIMANO Altus (21)
Cassette
SHIMANO HG20-7 12-32 (7)
Crank
PROWHEEL 48-38-28 teeth 170 / 175 mm cranks
Chain
KMC Z51
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO 32 holes
Rear Hub
QUANDO 32 holes
Rims
alloy 32 holes
Spokes
black steel
Tires
AUTHOR Speed Master 700 x 42c
Brakes
Brakes
TEKTRO 855
Cockpit
Stem
ZOOM alloy
Handlebar
steel 20 mm 660mm
Grips
AUTHOR high density foam
Seat
Saddle
AUTHOR Courier
Seatpost
ZOOM alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 628 mm | 643 mm | 658 mm | 666 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1067 mm | 1082 mm | 1097 mm | 1105 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 168 cm | 178 cm | 188 cm | 200 cm |
About this model
Horizon is part of the Author Horizon model. Author released 17 bikes variations of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Hybrid bikes
Our math shows that the average cost of a dependable Hybrid bike is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Average weight for Hybrid bikes
Hybrid bikes have an average weight of 13.85 kg (30.53 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Horizon weighs 13.2 kg (29.1 lbs) and is slightly lighter than the average. In conclusion, the average Hybrid bike weighs 4.92% more than Horizon.
Horizon components
Fork
This bike has the RST NEON fork installed. The fork’s travel is 60mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Horizon 2016 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 4 sizes. They vary from 150 cm – 200 cm (4.92 ft – 6.56 ft). In short, you can easily find one that suits you.
