Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 60mm -
Fork RST NOVA
-
Groupset Tourney, Acera -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
150cm - 168cm
18"
165cm - 178cm
20"
175cm - 188cm
22"
185cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
alloy 6061
Suspension Fork
RST Nova ML lock out (60 mm)
Drivetrain
Rear Derailleur
SHIMANO TX800
Front Derailleur
SHIMANO TY700 (31.8)
Shift Levers
SHIMANO Acera (24)
Cassette
SHIMANO HG200-8 12-32 (8)
Crank
PROWHEEL 48-38-28 teeth 170 / 175 mm cranks
Chain
KMC Z8.1
Pedals
AUTHOR Non Slip resin
Wheels
Front Hub
QUANDO Disc 32 holes
Rear Hub
QUANDO Disc 32 holes
Rims
AUTHOR Xenon 29 32 holes
Spokes
hi-ten black
Tires
AUTHOR Cross 700 x 38c
Brakes
Brakes
TEKTRO disc hydraulic (6" rotors)
Cockpit
Stem
ZOOM alloy
Handlebar
hi-ten 20 mm 680 mm
Grips
AUTHOR ErgoGrip
Seat
Saddle
AUTHOR Sphere
Seatpost
ZOOM alloy (27.2)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" | 22" |
|---|---|---|---|---|
| Front Center | 637 mm | 652 mm | 668 mm | 676 mm |
| Rake | 68 mm | 68 mm | 68 mm | 68 mm |
| Top Tube Length | 566 mm | 586 mm | 606 mm | 626 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 180 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1076 mm | 1091 mm | 1107 mm | 1115 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 150 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 168 cm | 178 cm | 188 cm | 200 cm |
Model Overview
Horizon is part of the Author Horizon model. Author released 17 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
According to our calculations, the average cost of a Hybrid bike that is reliable is 562$. However, this doesn’t mean that if you spend less money on a Hybrid bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Author Horizon it’s weighing 14.3 kg (31.53 lbs). At this weight, is slightly heavier than average. In short, the average Hybrid bike weight is 3.25% lower than this one.
Overview of components
Fork
This bike has the RST NOVA fork installed. The fork’s travel is 60mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Horizon are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Author Horizon bike has 4 sizes, in the range of 150 cm – 200 cm (4.92 ft – 6.56 ft). In conclusion, finding one for you shouldn’t be a problem.
