Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RST F1RST
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
14"
140cm - 158cm
16"
155cm - 173cm
18"
170cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted hydroformed alloy 6061 27.5" (ASL)
Suspension Fork
RST F1RST 27.5 air, lock out (100 mm)
Drivetrain
Rear Derailleur
SHIMANO XT
Front Derailleur
SHIMANO Deore (34.9)
Shift Levers
SHIMANO Deore (30)
Cassette
SHIMANO HG50-10 11-36 (10)
Crank
SHIMANO Deore 40-30-22 teeth 170 / 175 mm cranks
Chain
SHIMANO HG54
Pedals
SHIMANO M520 clipless
Wheels
Front Hub
AUTHOR Xenon 32 holes
Rear Hub
AUTHOR Xenon 32 holes
Rims
AUTHOR Radon Pro 27.5 32 holes
Spokes
black stainless steel 2.0 mm
Tires
VITTORIA Barzo kevlar 27.5" x 2.10"
Brakes
Brakes
SHIMANO Alivio disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 640 / 660 mm
Grips
AUTHOR GripLock foam
Seat
Saddle
AUTHOR Fenix
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14" | 16" | 18" |
|---|---|---|---|
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 612 mm | 633 mm | 658 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 552 mm | 567 mm | 592 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm |
| Head Tube Angle | 70 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1040 mm | 1061 mm | 1086 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 140 cm | 155 cm | 170 cm |
| Rider Max Height | 158 cm | 173 cm | 188 cm |
About this model
Instinct ASL is part of the Author Instinct model. Author released 20 bikes variations of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
Crosscountry bikes weigh an average of 12.4 kg (27.34 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Instinct ASL weighs 12.5 kg (27.56 lbs) and is slightly heavier than the average. In conclusion, the average Crosscountry bike weighs 0.81% less than Instinct ASL.
Instinct ASL components
Fork
The Instinct ASL comes factory-installed with the RST F1RST fork. This has a travel range of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Author Instinct ASL 2016, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Author Instinct ASL is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 140 cm – 188 cm (4.59 ft – 6.17 ft). In conclusion, finding one for you shouldn’t be a problem.
