Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RST AERIAL
-
Groupset Deore, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
16"
148cm - 162cm
18"
160cm - 175cm
20"
173cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
double butted alloy 6061 27.5" (ASL) - hydroforming
Suspension Fork
RST Aerial 27.5 TnL air, lock out (100 mm)
Drivetrain
Rear Derailleur
SHIMANO Deore
Front Derailleur
SHIMANO Alivio (34.9)
Shift Levers
SHIMANO Alivio (27)
Cassette
SHIMANO HG400-9 11-34 (9)
Crank
SHIMANO Alivio 40-30-22 teeth 170 / 175 mm cranks
Chain
SHIMANO HG53
Pedals
AUTHOR alloy
Wheels
Front Hub
AUTHOR Xenon Disc 32 holes
Rear Hub
AUTHOR Xenon Disc 32 holes
Rims
AUTHOR Radon Pro 27.5 32 holes
Spokes
black stainless steel 2.0 mm
Tires
VITTORIA Mezcal 27.5" x 2.10"
Brakes
Brakes
TEKTRO Gemini WH disc hydraulic (6" rotors)
Cockpit
Stem
AUTHOR alloy
Handlebar
AUTHOR 15 mm 640 / 660 mm
Grips
AUTHOR GripLock foam
Seat
Saddle
AUTHOR Fenix
Seatpost
AUTHOR alloy (31.6)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 16" | 18" | 20" |
|---|---|---|---|
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm |
| Front Center | 618 mm | 638 mm | 652 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Top Tube Length | 551 mm | 576 mm | 596 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1045 mm | 1065 mm | 1079 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 148 cm | 160 cm | 173 cm |
| Rider Max Height | 162 cm | 175 cm | 185 cm |
About this model
Traction ASL belongs to the Author Traction model. There are 30 bikes that carry this model name. Take a sneak peek at all Author Traction bikes models from 2015, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Average weight for Crosscountry bikes
If we make a quick analysis of the average weight of a Crosscountry bike, we get 12.4 kg (27.34 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Traction ASL weighs 13.4 kg (29.54 lbs) and is a bit heavier than the average. To sum up, it’s 8.06% heavier than the average weight of Crosscountry bikes.
Traction ASL components
Fork
This bike has the RST AERIAL fork installed. The fork’s travel is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Traction ASL 2015 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 148 cm – 185 cm (4.86 ft – 6.07 ft). In short, you can easily find one that suits you.
