Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 65mm -
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Disc Brake Design
Suspension Fork
HL 187 Suspension fork, 65mm Travel,
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TY510
Shift Levers
Shimano EF500 21-Speed
Cassette
Shimano HG200 Cassette, 12-32T 7 Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z-7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505 Alloy, Rear TY505 Alloy Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505 Alloy, Rear TY505 Alloy Centrelock Cassette 32H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c AV valve
Brakes
Brakes
Tektro Aries Mechanical Disc, 160mm rotors
Brake Levers
Shimano EF500
Cockpit
Handlebar
Alloy Riser, 31.8mm, 15mm rise, 5 deg sweep, 680mm
Grips
Zero Comfort
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Comfort
Seatpost
Alloy 27.2mm Micro Adjust with Suspension, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.57 mm | 1.57 mm |
| Front Center | 622 mm | 633 mm | 658 mm | 664 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 80 mm | 91 mm | 80 mm | 91 mm |
| Stack | 600 mm | 619 mm | 633 mm | 648 mm |
| Reach | 379 mm | 393 mm | 403 mm | 414 mm |
| Top Tube Length | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 425 mm | 480 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm | 165 mm | 180 mm |
| Chainstay Length | 456 mm | 456 mm | 446 mm | 456 mm |
| Wheelbase | 1070 mm | 1081 mm | 1096 mm | 1112 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 684 mm | 732 mm | 767 mm | 804 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Discovery 1 belongs to the Avanti Discovery model. There are 12 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Comfort bikes
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, even though the average price of a Comfort bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Discovery 1 components
Wheels size
As for the wheels, Avanti Discovery 1 2022, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Avanti Discovery 1 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Discovery 1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
