Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 65mm -
Fork Zoom
-
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Disc Brake Design
Suspension Fork
HL Zoom 187 Suspension fork, 65mm Travel, Mechanical Lock-out
Drivetrain
Rear Derailleur
Shimano TX800
Front Derailleur
Shimano TY710
Shift Levers
Shimano Altus 24-Speed
Cassette
Shimano HG200 Cassette, 12-32T 8 Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC X8
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Shimano TX505 Centrelock Cassette 36H
Rear Hub
Shimano TX505 Centrelock Cassette 36H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c AV valve
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano
Cockpit
Handlebar
Alloy Riser, 31.8mm, 15mm rise, 5 deg sweep, 680mm
Grips
Zero Comfort
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Comfort
Seatpost
Alloy 27.2mm Micro Adjust with Suspension, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.58 mm | 1.57 mm | 1.57 mm |
| Front Center | 622 mm | 633 mm | 648 mm | 664 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 80 mm | 91 mm | 91 mm | 91 mm |
| Stack | 600 mm | 619 mm | 633 mm | 648 mm |
| Reach | 379 mm | 393 mm | 403 mm | 414 mm |
| Top Tube Length | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 425 mm | 480 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm | 165 mm | 180 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1070 mm | 1081 mm | 1096 mm | 1112 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 684 mm | 732 mm | 767 mm | 804 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Discovery 2 is part of the Avanti Discovery model. There are 12 bikes that carry this model name. Take a sneak peek at all Avanti Discovery bikes models from 2023, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort bikes average price
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, even though the average price of a Comfort bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Discovery 2 components
Fork
This bike has the Zoom fork installed. The fork’s travel is 65mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Discovery 2 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Discovery 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Avanti Discovery 2 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
