Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 65mm -
Groupset Tourney, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Low Step Disc Brake Design
Suspension Fork
HL 187 Suspension fork, 65mm Travel, Mechanical Lock-out
Drivetrain
Rear Derailleur
Shimano TX800
Front Derailleur
Shimano TY710
Shift Levers
Shimano Altus 24-Speed
Cassette
Shimano HG200 Cassette, 12-32T 8 Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC X8
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Shimano TX505 Centrelock Cassette 36H
Rear Hub
Shimano TX505 Centrelock Cassette 36H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c AV valve
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano
Cockpit
Handlebar
Alloy Riser 31.8mm, 17 deg rise, 15deg sweep
Grips
Zero Comfort
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Comfort
Seatpost
Alloy 27.2mm Micro Adjust with Suspension
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.64 mm | 1.63 mm | 1.64 mm |
| Front Center | 610 mm | 632 mm | 647 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 82 mm | 81 mm | 82 mm |
| Stack | 605 mm | 624 mm | 643 mm |
| Reach | 368 mm | 382 mm | 391 mm |
| Top Tube Length | 541 mm | 561 mm | 581 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 350 mm | 425 mm | 480 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1057 mm | 1079 mm | 1094 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 611 mm | 595 mm | 587 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Discovery 2 Low is part of the Avanti Discovery model. 12 bikes variations carry this model name so far. Take a sneak peek at all Avanti Discovery bikes models from 2023, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Comfort bikes
If you want to purchase a solid Comfort bike, it is important to know that the average cost is 360$. However, even though the average price of a Comfort bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Discovery 2 Low components
Wheels
When it comes to wheels, the Discovery 2 Low bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, finding one for you shouldn’t be a problem.
