Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 60mm -
Fork Suntour NEX
-
Groupset Acera, Shimano -
Suspension Hardtail -
Motor Bosch 250W 40Nm mid-drive -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, fully-integrated battery and internal cables
Suspension Fork
Suntour NEX HLO, 60mm, hydraulic lockout
Drivetrain
Rear Derailleur
Shimano Acera 8 speed
Shift Levers
Shimano M315 8 speed
Cassette
Shimano HG31 Cassette, 8-speed 11-32T
Crank
Prowheel Alloy, 38T
Chain
KMC
Pedals
VP retro with alloy body and rubber gripper
Wheels
Front Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano TX505 Centrelock Cassette 36H
Rear Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano TX505 Centrelock Cassette 36H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Small Block 8 29 x 1.75 with K Shield, reflective logos & AV tube
Brakes
Brakes
Tektro M275 Hydraulic Disc, 180 front/160 rear Centrelock Rotors
Brake Levers
Tektro hydraulic
Cockpit
Handlebar
Alloy riser bar, 15deg rear sweep
Grips
Ergonomic comfort
Headset
Integrated Threadless 1/8th
Seat
Saddle
Selle Royal Lookin comfort with RoyalGel padding
Seatpost
Alloy Micro Adjust 31.6mm
Motor & Battery
Motor
Bosch G3 Active Line
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.53 mm | 1.59 mm |
| Front Center | 659 mm | 664 mm | 669 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 71 mm | 71 mm |
| Stack | 611 mm | 632 mm | 651 mm |
| Reach | 409 mm | 412 mm | 410 mm |
| Top Tube Length | 600 mm | 610 mm | 620 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 456 mm | 495 mm | 535 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 130 mm | 170 mm |
| Chainstay Length | 478 mm | 478 mm | 478 mm |
| Wheelbase | 1130 mm | 1135 mm | 1140 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 777 mm | 810 mm | 842 mm |
| Wheels | 29" | 29" | 29" |
About this model
Explorer-E1 belongs to the Avanti E Explorer E1 model. There are 6 e-bikes that carry this model name. Take a sneak peek at all Avanti E Explorer E1 e-bikes models from 2022, by clicking here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for General Urban e-bikes
According to our math, the average price for a trustworthy General Urban e-bike is 2098$. However, even though the average price of a General Urban e-bike is lower, you might still be able to get a top-quality e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This e-bike has the Suntour NEX fork installed. The fork’s travel is 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Explorer-E1 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Avanti Explorer-E1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
