Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 60mm -
Fork Suntour NEX
-
Groupset Acera, Shimano -
Suspension Hardtail -
Motor Bosch 250W 40Nm mid-drive -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Low-step Alloy with Ultra Light butted tubing, fully-internal battery and internal cables
Suspension Fork
SR NEX HLO, 60mm, hydraulic lockout
Drivetrain
Rear Derailleur
Shimano Acera 8 speed
Shift Levers
Shimano M315 8 speed
Cassette
Shimano HG31 Cassette, 8-speed 11-32T
Crank
Prowheel Alloy, 38T
Chain
KMC
Pedals
VP retro with alloy body and rubber gripper
Wheels
Front Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano TX505 Centrelock Cassette 36H
Rear Hub
Front: Shimano TX505 Centrelock 36H, Rear: Shimano TX505 Centrelock Cassette 36H
Rims
Alex TD26 Double-wall Alloy 36H
Spokes
Stainless Steel
Tires
Kenda Small Block 8 29 x 1.75 with K Shield, reflective logos & AV tube
Brakes
Brakes
Tektro M275 Hydraulic Disc, 180 front/160 rear Centrelock Rotors
Brake Levers
Tektro hydraulic
Cockpit
Handlebar
Alloy riser bar, 15deg rear sweep
Grips
Ergonomic comfort
Headset
Integrated Threadless 1/8th
Seat
Saddle
Selle Royal Lookin comfort with RoyalGel padding
Seatpost
Alloy Micro Adjust 31.6mm
Motor & Battery
Motor
Bosch G3 Active Line
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD/LG |
|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.59 mm |
| Front Center | 650 | 655 mm |
| Rake | 51 mm | 50 mm |
| Trail | 73 mm | 74 mm |
| Stack | 604 mm | 623 mm |
| Reach | 392 mm | 391 mm |
| Top Tube Length | 578 mm | 588 mm |
| Seat Tube Angle | 73 ° | 72.5 ° |
| Seat Tube Length | 415 mm | 455 mm |
| Head Tube Angle | 70 ° | 70 ° |
| Head Tube Length | 130 mm | 150 mm |
| Chainstay Length | 471 mm | 471 mm |
| Wheelbase | 1114 mm | 1119 mm |
| Bottom Bracket Drop | 60 mm | 60 mm |
| Standover Height | 700 | 713 mm |
| Wheels | 29" | 29" |
About this model
Explorer-E1 Low belongs to the Avanti E Explorer E1 model. Avanti launched 6 e-bikes of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for General Urban e-bikes
According to our calculations, the average cost of a General Urban e-bike that is reliable is 2098$. However, this doesn’t mean that if you spend less money on a General Urban e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Avanti Explorer-E1 Low 2022 e-bike is equipped with the Suntour NEX fork, and has 60mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Explorer-E1 Low 2022 e-bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
