Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT R4 Carbon, Endurance Road Geometry, Universal component capability, 142x12mm Thru Axle, Flat Mount Disc Brake
Suspension Fork
ADT R5 Carbon Integrated with 1.5"-1 1/8" Steerer, 100x12mm Thru Axle, Flat Mount Disc Brake
Drivetrain
Rear Derailleur
Shimano Ultegra R8000
Front Derailleur
Shimano 105 R7000
Shift Levers
Shimano ST-R7020 22-Speed
Cassette
Shimano 105 R7000 11-28T 11-Speed
Crank
Shimano 105 Series Compact 50/34T, with 4-arm crank
Bottom Bracket
Shimano BB-R500 Press Fit
Chain
KMC X11
Wheels
Front Hub
Shimano RS470 28H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rear Hub
Shimano RS470 28H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rims
Weinmann XC210 wheelset, Double-wall alloy 28H rims
Spokes
Double butted Stainless
Tires
Kenda Valkyrie 700x30c, with IronCap Belt
Brakes
Brakes
Shimano 105 BR-RS7020 Hydraulic Disc, 140mm Rotors
Brake Levers
Shimano R7000 Hydraulic Disc
Cockpit
Handlebar
Syncros Creston 2.0 Alloy 31.8mm, 52- 53.5=424mm, 55-60=444mm (measured at drops)
Grips
Zero Anti-slip, Shockproof
Headset
Tapered Integrated Aheadset 1-1/8" - 1-1.5"
Seat
Saddle
Syncros Tofino 2.5
Seatpost
Alloy Micro Adjust 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM/MD | MD | MD/LG | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.47 mm | 1.49 mm | 1.53 mm | 1.57 mm |
| Bottom Bracket Height | 263 mm | 263 mm | 264 mm | 264 mm | 266 mm |
| Front Center | 586 mm | 591 mm | 598 mm | 608 mm | 620 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 43 mm | 54 mm | 58 mm | 54 mm | 54 mm |
| Stack | 530 mm | 540 mm | 554 mm | 580 mm | 602 mm |
| Reach | 354 mm | 367 mm | 372 mm | 379 mm | 384 mm |
| Top Tube Length | 511 mm | 526 mm | 541 mm | 556 mm | 571 mm |
| Seat Tube Angle | 75.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 476 mm | 448 mm | 497 mm | 515 mm | 526 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 190 mm | 215 mm |
| Chainstay Length | 403 mm | 403 mm | 406 mm | 406 mm | 409 mm |
| Wheelbase | 978 mm | 983 mm | 993 mm | 1003 mm | 1019 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 72 mm | 72 mm | 70 mm |
| Standover Height | 738 mm | 746 mm | 771 mm | 781 mm | 797 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Giro ER-C is an Avanti Giro model. 24 bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Endurance bikes average price
If you want an acceptable Endurance bike you should know that the average price is 2346$. However, even though the average price of an Endurance bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Giro ER-C components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When leaving the production line, the Giro ER-C model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Giro ER-C has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
