Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultra Lite Butted Alloy, Gravel Geometry, 142x12mm Thru axle, Disc, dropper compatible
Suspension Fork
Alloy Gravel with 1.5"-1 1/8" Steerer, 100x12mm Thru Axle, Flat Mount Disc Brake
Drivetrain
Rear Derailleur
Shimano Claris 8sp
Front Derailleur
Shimano Claris Brazed -on type
Shift Levers
Shimano Claris STI 16sp, with Shimano cable
Cassette
Shimano CS-HG31-8 11-34 8-Speed
Crank
Shimano Claris Compact 34/50T alloy
Bottom Bracket
Shimano Hollowtech II
Chain
CN-HG71-8
Wheels
Front Hub
Shimano RS470 32H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rear Hub
Shimano RS470 32H Alloy Centrelock Cassette, w/12x100 and 12x142 t/axle, w/Syncros SwitchBolt axle
Rims
Alex GX26, double-wall alloy, TL-ready, hooked 23mm (inner), 32H
Spokes
Stainless
Tires
Kenda Piedmont 700x40c, DTC compound, with K-Shield protection
Brakes
Brakes
Tektro MD-C550P Dual Piston Mechanical Disc, 6-bolt, 160mm rotors
Brake Levers
Shimano Claris with reach adjust
Cockpit
Handlebar
Syncros Creston 2.0 Alloy 10deg Flare 31.8mm, 53=461mm, 54.5-56=481mm, 57.5-59=501mm (measured at drops)
Grips
Super-grip, Shockproof
Headset
Acros Integrated Aheadset 1-1/8-1.5", internal cable routing
Seat
Saddle
Syncros Belcarra 2.5
Seatpost
Syncros 3.0 Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM/MD | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.474 mm | 1.485 mm | 1.495 mm | 1.505 mm | 1.514 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 616 mm | 633 mm | 649 mm | 665 mm | 682 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm | 75 mm | 75 mm |
| Stack | 560 mm | 579 mm | 598 mm | 617 mm | 636 mm |
| Reach | 380 mm | 390 mm | 400 mm | 410 mm | 420 mm |
| Top Tube Length | 530 mm | 545 mm | 560 mm | 575 mm | 590 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 485 mm | 510 mm | 535 mm | 560 mm | 585 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1041 mm | 1058 mm | 1075 mm | 1091 mm | 1108 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 774 mm | 796 mm | 817 mm | 839 mm | 861 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Gran Durance 1 is an Avanti Gran model. Avanti launched 12 bikes of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Gran Durance 1 components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
When leaving the production line, the Gran Durance 1 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Gran Durance 1 comes with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
