Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox ZEB
-
Groupset NX Eagle, FSA -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Powertube 625Wh Internal -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultralight tubing, 150mm travel, cartridge bearing pivots, 1.5" tapered headtube, PowerTube internal battery
Suspension Fork
Rockshox ZEB Charger R, 160mm, air spring, 1.5" taper, rebound adjust, lock-out, Boost 110 15mm axle - S=27.5, M/L/XL=29er
Rear Shock
Rockshox Delux Select R, Debon Air, rebound adjust
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle, 12sp
Cassette
SRAM PG-1210 Cassette, 11-50T, 12 speed
Crank
FSA Gen 4 Bosch ISIS, 34T SRAM X-Sync chainwheel
Bottom Bracket
Bosch, press-fit
Chain
SRAM SX Eagle
Wheels
Front Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano MT400 148x12 32H
Rear Hub
Front: Shimano MT400 110x15 32H, Rear: Shimano MT400 148x12 32H
Rims
Tubeless-Ready Double-wall Alloy 32H
Spokes
Sapim Stainless Steel
Tires
Kenda Regolith 27.5/29 x2.6", 120tpi, folding, SCT (Tubeless Ready)
Brakes
Brakes
Shimano M420 hydraulic, 203mm rotors
Brake Levers
Shimano M401 hydraulic
Cockpit
Handlebar
Syncros Hixon 2.0, 31.8mm, with 12mm rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Integrated Threadless 1 1/8th - 1.5" (with extra lower geometry adjust cup for 27.5+ )
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G4 Performance Line CX
Battery
Bosch Powertube 625Wh Internal
Charger
Bosch Std 4A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.42 mm | 1.37 mm | 1.31 mm |
| Bottom Bracket Height | 330 mm | 349 mm | 349 mm | 349 mm |
| Front Center | 754 mm | 779 mm | 808 mm | 844 mm |
| Rake | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 106 mm | 115 mm | 116 mm | 116 mm |
| Stack | 639 mm | 639 mm | 649 mm | 662 mm |
| Reach | 424 mm | 449 mm | 474 mm | 504 mm |
| Top Tube Length | 587 mm | 612 mm | 640 mm | 675 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 404 mm | 440 mm | 472 mm | 517 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 145 mm |
| Chainstay Length | 466 mm | 466 mm | 466 mm | 466 mm |
| Wheelbase | 1219 mm | 1244 mm | 1273 mm | 1309 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 770 mm | 794 mm | 814 mm | 845 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Hammer-E LT2 belongs to the Avanti E Hammer E model. There are 6 e-bikes that carry this model name. You can easily view all of the Avanti E Hammer E e-bikes models from 2023, here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Enduro e-bikes
If you want to purchase a solid Enduro e-bike, it is important to know that the average cost is 4785$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Enduro e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The fork installed on this bike is the RockShox ZEB model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Hammer-E LT2 has a rear shock with a travel of 150mm. The model Rockshox Delux Select R is the one installed in this e-bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Hammer-E LT2 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Avanti Hammer-E LT2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Avanti Hammer-E LT2 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
