Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 27.5" -
Travel Front 160mm -
Travel Rear 145mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Ultralight Butted tubing, 145mm travel, cartridge bearing pivots, 1.5" tapered headtube, PF92 BB, 12 x 148m, stash box with tools
Suspension Fork
Rockshox 35 Silver TK Solo Air, 160mm, air spring, 1.5" taper, fixed rebound, lock-out, Boost 110 15mm axle - S=27.5, M/L/XL=29er
Rear Shock
Rockshox Delux Select + Debonair, rebound adjust
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle, 12 speed
Cassette
SRAM PG-1210 Cassette, 11-50T, 12 speed
Crank
SRAM X1 1000 Eagle,DUB, 32T
Bottom Bracket
SRAM DUB Pressfit
Chain
SRAM SX Eagle
Wheels
Front Hub
Front: Alloy, 110x15mm 32H, Rear: Alloy 148x12mm, 32H
Rear Hub
Front: Alloy, 110x15mm 32H, Rear: Alloy 148x12mm, 32H
Rims
Alex EXR 30 Double-wall Alloy with eyelet 32H, Tubeless Ready
Spokes
Stainless steel
Tires
Fr: Maxxis Minion DHF 3CMaxxTerra/EXO 2.5"; Rr Maxxis Aggressor, 3CMaxxTerra/EXO 2.3" (2.5" on S size). Foldable, Tubeless Ready
Brakes
Brakes
Shimano MT420 hydraulic, 203 front/180mm rear rotors
Brake Levers
Shimano MT401hydraulic
Cockpit
Handlebar
Syncros Hixon 2.0 31.8mm, with 12mm rise, 9 deg sweep
Grips
Syncros Lock-on
Headset
Integrated Threadless 1 1/8th - 1.5" (with extra lower geometry adjust cup for 27.5+ )
Seat
Saddle
Syncros ER2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.439 mm | 1.374 mm | 1.36 mm | 1.355 mm |
| Bottom Bracket Height | 325 mm | 344 mm | 344 mm | 344 mm |
| Front Center | 757 mm | 783 mm | 804 mm | 828 mm |
| Rake | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 106 mm | 115 mm | 116 mm | 115 mm |
| Stack | 620 mm | 625 mm | 639 mm | 657 mm |
| Reach | 431 mm | 455 mm | 470 mm | 485 mm |
| Top Tube Length | 575 mm | 600 mm | 620 mm | 641 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 440 mm | 480 mm | 515 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 95 mm | 100 mm | 115 mm | 135 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1193 mm | 1219 mm | 1240 mm | 1264 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 740 mm | 768 mm | 783 mm | 808 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Hammer LT1 completes the Avanti Hammer model. Avanti launched 17 bikes of this model so far. You can easily view all of the Avanti Hammer bikes models from 2022, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Hammer LT1 components
Fork
The Hammer LT1 comes factory-installed with the RockShox 35 Silver fork. This has a travel range of 160mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Avanti Hammer LT1 bike has the Rockshox Delux Select + Debonair model installed, and has a travel of 145mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Avanti Hammer LT1 2022, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Avanti Hammer LT1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Hammer LT1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
