Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCE
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Replaceable Hanger, internal brake cable
Suspension Fork
SR Suntour XCE, 100mm Travel
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TY500
Shift Levers
Shimano Altus M315 RapidFire Plus 21-Speed
Cassette
Shimano HG200 Cassette, 12-28T 7-Speed
Crank
Shimano TY301 42/34/24T
Bottom Bracket
Cartridge
Chain
KMC Z-7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rims
Weinmann XRD28 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Aptor 27.5x2.20 or 29x2.20" MTB tyre with AV tube
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano MT200 Hydraulic
Cockpit
Handlebar
Alloy 31.8 with 9deg back sweep and 12mm rise, XS=640mm,S=660mm, M-XXL=680mm
Grips
Zero Strike Dual Compound
Headset
Semi-Integrated Threadless 1-1/8"
Seat
Saddle
Zero Zealth Sport
Seatpost
Zero Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Front Center | 628 mm | 644 mm | 659 mm | 664 mm | 680 mm | 673 mm |
| Rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 549 mm | 564 mm | 584 mm | 599 mm | 614 mm | 619 mm |
| Seat Tube Angle | 73.3 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 480 mm | 525 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1049 mm | 1066 mm | 1081 mm | 1092 mm | 1108 mm | 1101 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 52 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 716 mm | 732 mm | 757 mm | 778 mm | 808 mm | 837 mm |
| Wheels | 27" | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
Montari 1 is an Avanti Montari model. There are 21 bikes that carry this model name. Take a sneak peek at all Avanti Montari bikes models from 2023, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our math, the average price for a trustworthy Fitness bike is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Montari 1 components
Fork
The Suntour XCE is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the Montari 1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Avanti Montari 1 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, finding one for you shouldn’t be a problem.
