Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR 32
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 63Nm mid-drive -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR32 ATB, 100 mm, fixed rebound and lockout QR
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9 speed
Shift Levers
Shimano Alivio 9sp
Cassette
Sunrace CSM90 9 speed 11-36T
Crank
FSA Gen 3 Bosch, 32T
Bottom Bracket
Bosch, press-fit
Chain
KMC E9 E-bike chain
Wheels
Front Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rear Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rims
Alex DP 27 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Slant Six 29x2.35"
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Low riser bar
Grips
Syncros Lock-On
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G3 Performance Line
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm | 1.52 mm | 1.51 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 651 mm | 659 mm | 674 mm | 675 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 92 mm | 92 mm | 92 mm | 81 mm |
| Stack | 623 mm | 628 mm | 632 mm | 648 mm |
| Reach | 396 mm | 402 mm | 416 mm | 428 mm |
| Top Tube Length | 585 mm | 593 mm | 602 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 71 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1125 mm | 1133 mm | 1148 mm | 1149 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 743 mm | 762 mm | 768 mm | 799 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Montari-E Performance completes the Avanti E Montari E model. 9 e-bikes variations carry this model name so far. You can easily view all of the Avanti E Montari E e-bikes models from 2021, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry e-bikes
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, this doesn’t mean that if you spend less money on a Crosscountry e-bike, you couldn’t get a decent one. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Montari-E Performance components
Fork
The fork installed on this bike is the Suntour XCR 32 model. The travel on this model is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Montari-E Performance 2021 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Avanti Montari-E Performance e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Montari-E Performance. Therefore, climbing or descending will be a breeze.
