Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame aluminium -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCR 32
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 63Nm mid-drive -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR32 ATB, 100 mm, fixed rebound and lockout QR
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9 speed
Shift Levers
Shimano Alivio 9sp
Cassette
Sunrace CSM90 9 speed 11-36T
Crank
FSA Gen 3 Bosch, 32T
Bottom Bracket
Bosch, press-fit
Chain
KMC E9 E-bike chain
Wheels
Front Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rear Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rims
Alex DP 27 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Slant Six 29x2.35"
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Low riser bar
Grips
Syncros Lock-On
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G3 Performance Line
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm | 1.52 mm | 1.51 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 651 mm | 659 mm | 674 mm | 675 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 92 mm | 92 mm | 92 mm | 81 mm |
| Stack | 623 mm | 628 mm | 632 mm | 648 mm |
| Reach | 396 mm | 402 mm | 416 mm | 428 mm |
| Top Tube Length | 585 mm | 593 mm | 602 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 71 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1125 mm | 1133 mm | 1148 mm | 1149 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 743 mm | 762 mm | 768 mm | 799 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Montari-E Performance completes the Avanti E Montari E model. Avanti launched 9 e-bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry e-bikes
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, even though the average price of a Crosscountry e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Montari-E Performance components
Fork
The Suntour XCR 32 is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Montari-E Performance e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Avanti Montari-E Performance comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
