Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork Suntour XCR
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor Bosch 250W 63Nm mid-drive -
Battery Bosch Powertube 500Wh Internal -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AL-6061 Alloy with Ultra Light butted tubing, tapered head tube, Powertube internal battery and internal cables
Suspension Fork
Suntour XCR32 ATB, 100 mm, fixed rebound and lockout QR
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9 speed
Shift Levers
Shimano Alivio 9sp
Cassette
Sunrace CSM90 9 speed 11-36T
Crank
FSA Gen 3 Bosch, 32T
Bottom Bracket
Bosch, press-fit
Chain
KMC E9 E-bike chain
Wheels
Front Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rear Hub
Front: Alex DP 27 Double-wall Alloy 32H, Rear: Formula Alloy Centrelock Cassette 148x12mm thru axle
Rims
Alex DP 27 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Slant Six 29x2.35"
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 180 Centrelock Rotors
Brake Levers
Shimano MT200 hydraulic
Cockpit
Handlebar
Low riser bar
Grips
Syncros Lock-On
Headset
Integrated Threadless 1 1/8th - 1.5"
Seat
Saddle
Syncros ER 2.5
Seatpost
Syncros Duncan Dropper 31.6mm with internal cable routing
Motor & Battery
Motor
Bosch G3 Performance Line
Battery
Bosch Powertube 500Wh Internal
Charger
Bosch Std 2A Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.57 mm | 1.56 mm | 1.52 mm | 1.51 mm |
| Bottom Bracket Height | 286 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 651 mm | 659 mm | 674 mm | 675 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 85 mm | 92 mm | 92 mm | 81 mm |
| Stack | 623 mm | 628 mm | 632 mm | 648 mm |
| Reach | 396 mm | 402 mm | 416 mm | 428 mm |
| Top Tube Length | 585 mm | 593 mm | 602 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 71 ° |
| Head Tube Length | 120 mm | 125 mm | 130 mm | 140 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1125 mm | 1133 mm | 1148 mm | 1149 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 69 mm | 69 mm |
| Standover Height | 743 mm | 762 mm | 768 mm | 799 mm |
| Wheels | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Montari-E Performance is part of the Avanti E Montari E model. There are 9 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry e-bikes average price
If you want to purchase a solid Crosscountry e-bike, it is important to know that the average cost is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Montari-E Performance comes factory-installed with the Suntour XCR fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The Montari-E Performance 2023 e-bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Avanti Montari-E Performance is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Avanti Montari-E Performance e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
