Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Groupset microSHIFT XCD -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
158cm - 167cm
SM
165cm - 173cm
MD
169cm - 180cm
LG
177cm - 186cm
XL
183cm - 191cm
XXL
186cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Formtech Alloy, Replaceable Hanger, internal brake cable
Suspension Fork
HL Vaxa 860 Air RL/O RA, 100mm travel, 32mm stanchions, Hydraulic Rebound Adjust
Drivetrain
Rear Derailleur
Microshift XCD 11sp with Clutch
Shift Levers
Microshift XCD 11sp Trail trigger w/Sealed Bearing
Cassette
Microshift XCD cassette, 11-46T, 11sp
Crank
ProWheel Charm, forged alloy crank, 36T narrow/wide Chaninwheel
Bottom Bracket
Integrated with alloy CNC outboard bearing cups
Chain
KMC X-11 11sp
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Joytech alloy cassette disc 32H
Rear Hub
Joytech alloy cassette disc 32H
Rims
Weinmann XRD28 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Aptor 27.5x2.20 or 29x2.20" MTB tyre with AV tube
Brakes
Brakes
Tektro M275 Hydraulic
Brake Levers
Tektro M275 Hydraulic
Cockpit
Handlebar
Alloy 31.8 with 9deg backsweep and 12mm rise
Grips
Zero Strike Dual Compound
Headset
Semi-Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Zealth Sport
Seatpost
Zero Alloy 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Front Center | 628 mm | 644 mm | 659 mm | 664 mm | 680 mm | 673 mm |
| Rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm |
| Top Tube Length | 549 mm | 564 mm | 584 mm | 599 mm | 614 mm | 619 mm |
| Seat Tube Angle | 73.3 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 480 mm | 525 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1049 mm | 1066 mm | 1081 mm | 1092 mm | 1108 mm | 1101 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 52 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 716 mm | 732 mm | 757 mm | 778 mm | 808 mm | 837 mm |
| Wheels | 27" | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 165 cm | 169 cm | 177 cm | 183 cm | 186 cm |
| Rider Max Height | 167 cm | 173 cm | 180 cm | 186 cm | 191 cm | 194 cm |
About this model
Montari MS 3 belongs to the Avanti Montari model. 21 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our math, the average price for a trustworthy Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Wheels
When leaving the production line, the Montari MS 3 model has 27.5″ aluminum wheels. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Montari MS 3 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
Avanti Montari MS 3 bike has 6 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, it won’t take much to find one that’s right for you.
