Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ADT 6061 Butted Formtech Ultralight Alloy Disc brake, internal cable routing, rack/fender compatible
Suspension Fork
SR NEX DS with 63mm Travel
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano TX510
Shift Levers
Shimano Altus 21-Speed
Cassette
Shimano HG200-7 12-28T 7-Speed
Crank
Shimano TY301 48/38/28T
Bottom Bracket
Cartridge
Chain
KMC Z7
Pedals
Nylon platform with ball bearings
Wheels
Front Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rear Hub
Front: Shimano TX505 Alloy, Rear: TY505 Alloy Centrelock Cassette 32H
Rims
Alex TD26 Double-wall Alloy 32H
Spokes
Stainless Steel
Tires
Kenda Piedmont 700 x 40c with K-Shield and AV valve
Brakes
Brakes
Shimano MT200 Hydraulic Disc, 160mm Rotors
Brake Levers
Shimano
Cockpit
Handlebar
Alloy 31.8 with 9deg back sweep and 12mm rise
Grips
Zero Strike Dual Compound
Headset
Integrated Aheadset 1-1/8"
Seat
Saddle
Zero Zealth Women's
Seatpost
Alloy Micro Adjust 27.2mm, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.68 mm | 1.55 mm | 1.56 mm |
| Front Center | 602 mm | 632 mm | 647 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 80 mm | 81 mm | 80 mm |
| Stack | 609 mm | 609 mm | 624 mm |
| Reach | 362 mm | 392 mm | 401 mm |
| Top Tube Length | 539 mm | 574 mm | 594 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 365 mm | 410 mm | 450 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 110 mm | 115 mm | 130 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1031 mm | 1063 mm | 1078 mm |
| Bottom Bracket Drop | 70 mm | 65 mm | 65 mm |
| Standover Height | 726 mm | 752 mm | 781 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
X-Plorer 1 Women’s completes the Avanti X Plorer model. 12 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The X-Plorer 1 Women’s comes factory-installed with the Suntour NEX fork. This has a travel range of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the X-Plorer 1 Women’s model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The X-Plorer 1 Women’s comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Avanti X-Plorer 1 Women’s bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In conclusion, you won’t have a problem finding one that suits you.
