Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
3K Torayca HMCF T1000 & T800
Suspension Fork
Basso Carbon
Drivetrain
Bottom Bracket
BB86x41.5 Pressfit Required
Cockpit
Stem
Basso Alloy
Headset
Integrated 1 1/2" - 1 1/8"
Seat
Seatpost
Basso Diamante SV Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 53cm | 56cm | 58cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.29 mm | 1.34 mm | 1.35 mm | 1.41 mm | 1.47 mm |
| Stack | 488 mm | 512 mm | 524 mm | 551 mm | 574 mm |
| Reach | 377 mm | 381 mm | 388 mm | 390 mm | 391 mm |
| Top Tube Length | 510 mm | 520 mm | 540 mm | 555 mm | 570 mm |
| Seat Tube Angle | 75 ° | 75 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 530 mm | 560 mm | 580 mm |
| Head Tube Angle | 71.8 ° | 72 ° | 72.3 ° | 73.5 ° | 73.5 ° |
| Head Tube Length | 90 mm | 115 mm | 127 mm | 145 mm | 169 mm |
| Chainstay Length | 395 mm | 395 mm | 395 mm | 397 mm | 401 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Diamante SV Frameset is a Basso Diamante model. 38 frames variations carry this model name so far. Take a sneak peek at all Basso Diamante frames models from 2020, by clicking here.
Model range prices
Basso Diamante “Egg Shell” LTD Frameset 2020 is the most affordable frame of this model and has a price of 4995$. On the other hand, Basso Diamante SV Disc “MAAP” LTD. Frameset 2020, is the most expensive and costs 5595$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Race frames average price
According to our math, the average price for a trustworthy Race frame is 2445$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5295$. In conclusion, this frame price is 116.56% more expensive than the price of the average Race frame.
Overview of components
Fork material
Diamante SV Frameset has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
