Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Deore, Alivio -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29" (27.5"), ultra lite AL-6061 tubing
Suspension Fork
Suntour XCM RL DS, 100 mm
Drivetrain
Rear Derailleur
Shimano Deore, RD-M592, Shadow
Front Derailleur
Shimano FD-M4000
Shift Levers
Shimano SL-M4000, 3x9-speed, rapidfire plus-shifter
Cassette
Shimano CS-HG201-9, 11-36t
Crank
Shimano FC-MT300, 40/30/22t
Bottom Bracket
Shimano Hollowtech II, BSA
Chain
KMC X9
Pedals
Wellgo LU895
Wheels
Front Hub
Shimano dynamo hub, DH-3D37, centerlock, disc
Rear Hub
Shimano, centerlock, disc, quick release
Rims
Shining DB29, disc
Spokes
stainless, black
Tires
Impac SmartPac, Kevlarguard, reflective stripe, 29x2.10" (27.5x2.10") Tubes: Schwalbe SV19B Light (29") / SV21B Light (27.5")
Brakes
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT10 rotor: 180/160 mm
Brake Levers
Shimano BL-MT200, hydraulic disc brake
Cockpit
Stem
Syncros 3.0, +/-6°
Handlebar
Syncros 3.0, riserbar, width: 700 mm
Grips
Syncros MTB
Headset
BGM FP-H807B, A-Headset, semi-integrated, 1 1/8"
Seat
Saddle
Syncros M3.0
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS7 | S7 | M7 | M9 | L9 | XL9 | XXL9 |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.49 mm | 1.61 mm | 1.58 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 300 mm | 303 mm | 303 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 628 mm | 644 mm | 659 mm | 649 mm | 664 mm | 679 mm | 673 mm |
| Rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 88 mm | 87 mm | 85 mm | 73 mm | 74 mm | 74 mm | 70 mm |
| Stack | 590 mm | 591 mm | 603 mm | 633 mm | 642 mm | 652 mm | 664 mm |
| Reach | 372 mm | 387 mm | 404 mm | 394 mm | 407 mm | 419 mm | 414 mm |
| Top Tube Length | 549 mm | 564 mm | 584 mm | 584 mm | 599 mm | 614 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 445 mm | 480 mm | 525 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 71 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm | 115 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1046 mm | 1063 mm | 1078 mm | 1074 mm | 1089 mm | 1104 mm | 1098 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 52 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 715 mm | 730 mm | 754 mm | 759 mm | 777 mm | 807 mm | 836 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
Revox 5 EQ belongs to the Bergamont Revox model. Bergamont released 120 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Crosscountry bikes average weight
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 16 kg (35.27 lbs), the Revox 5 EQ model is much heavier than average. To sum up, it’s 29.03% heavier than the average weight of Crosscountry bikes.
Revox 5 EQ components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Bergamont Revox 5 EQ 2020, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Bergamont Revox 5 EQ has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
