Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCR 32
-
Groupset Deore, Shimano -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29" (27.5"), ultra lite AL-6061 tubing
Suspension Fork
Suntour XCR32 RLR DS, 100 mm, remote lockout
Drivetrain
Rear Derailleur
Shimano Deore, RD-M6000, Shadow Plus
Front Derailleur
Shimano Deore, FD-M6025
Shift Levers
Shimano Deore, SL-M6000, 2x10-speed, rapidfire plus-shifter
Cassette
Shimano CS-HG500, 11-42t
Crank
Shimano FC-MT500, 36/26t
Bottom Bracket
Shimano Hollowtech II, BSA
Chain
KMC X10
Pedals
Wellgo LU895
Wheels
Front Hub
Shimano, centerlock, disc, quick release
Rear Hub
Shimano, centerlock, disc, quick release
Rims
Shining DB29, disc
Spokes
stainless, black
Tires
Schwalbe Smart Sam, Kevlarguard, 29x2.10" (27.5x2.10") Tubes: Schwalbe SV19B Light (29") / SV21B Light (27.5")
Brakes
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT10 rotor: 180/160 mm
Brake Levers
Shimano BL-MT200, hydraulic disc brake
Cockpit
Stem
Syncros 3.0, +/-6°
Handlebar
Syncros 3.0, riserbar, width: 700 mm
Grips
Syncros MTB
Headset
BGM FP-H807B, A-Headset, semi-integrated, 1 1/8"
Seat
Saddle
Syncros M3.0
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS7 | S7 | M7 | M9 | L9 | XL9 | XXL9 |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.49 mm | 1.61 mm | 1.58 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 300 mm | 303 mm | 303 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 628 mm | 644 mm | 659 mm | 649 mm | 664 mm | 679 mm | 673 mm |
| Rake | 42 mm | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 88 mm | 87 mm | 85 mm | 73 mm | 74 mm | 74 mm | 70 mm |
| Stack | 590 mm | 591 mm | 603 mm | 633 mm | 642 mm | 652 mm | 664 mm |
| Reach | 372 mm | 387 mm | 404 mm | 394 mm | 407 mm | 419 mm | 414 mm |
| Top Tube Length | 549 mm | 564 mm | 584 mm | 584 mm | 599 mm | 614 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 445 mm | 480 mm | 525 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 71 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 115 mm | 125 mm | 115 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1046 mm | 1063 mm | 1078 mm | 1074 mm | 1089 mm | 1104 mm | 1098 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 52 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 715 mm | 730 mm | 754 mm | 759 mm | 777 mm | 807 mm | 836 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
About this model
Revox 6 completes the Bergamont Revox model. Bergamont released 120 bikes variations of this model so far. Take a sneak peek at all Bergamont Revox bikes models from 2020, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Average weight for Crosscountry bikes
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 13.8 kg (30.42 lbs), the Revox 6 model is considerably heavier than average. In short, the average Crosscountry bike weight is 11.29% lower than this one.
Overview of components
Fork
Bergamont Revox 6 2020 bike is equipped with the SunTour XCR 32 fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the Revox 6 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revox 6 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
