Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset Deore, SLX -
Suspension Hardtail -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
29" (27.5"), ultra lite AL-6061 tubing
Suspension Fork
RockShox Judy TK, 100 mm, coil
Drivetrain
Rear Derailleur
Shimano Deore, RD-M5120, Shadow Plus
Front Derailleur
Shimano SLX, FD-M7025
Shift Levers
Shimano Deore, SL-M5100, 2x11-speed, rapidfire plus-shifter
Cassette
Shimano Deore, CS-M5100, 11-42t
Crank
Shimano Deore, FC-M5100, 36/26t
Bottom Bracket
Shimano Hollowtech II, BSA
Chain
KMC X11
Pedals
Wellgo LU895
Wheels
Front Hub
Shimano, centerlock, disc, quick release
Rear Hub
Shimano, centerlock, disc, quick release
Rims
Alex X25, disc, width: 25 mm
Spokes
stainless, black
Tires
Kenda Booster, 29x2.40" (27.5x2.40") Tubes: Schwalbe SV19B Light (29") / SV21B Light (27.5")
Brakes
Brakes
Shimano BR-MT200, hydraulic disc brake, SM-RT10 rotor: 180/160 mm
Brake Levers
Shimano BL-MT200, hydraulic disc brake
Cockpit
Stem
Syncros 3.0, +/-6°
Handlebar
Syncros 3.0, riserbar, width: 700 mm
Grips
Syncros MTB
Headset
BGM PT1805, A-Headset, semi-integrated, 1 1/8"
Seat
Saddle
Syncros Tofino 2.5
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS7 | S7 | M9 | L9 | XL9 | XXL9 |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.53 mm | 1.61 mm | 1.58 mm | 1.56 mm | 1.6 mm |
| Bottom Bracket Height | 300 mm | 303 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 628 mm | 644 mm | 649 mm | 664 mm | 679 mm | 673 mm |
| Rake | 42 mm | 42 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 88 mm | 87 mm | 73 mm | 74 mm | 74 mm | 70 mm |
| Stack | 590 mm | 591 mm | 633 mm | 642 mm | 652 mm | 664 mm |
| Reach | 372 mm | 387 mm | 394 mm | 407 mm | 419 mm | 414 mm |
| Top Tube Length | 549 mm | 564 mm | 584 mm | 599 mm | 614 mm | 619 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 480 mm | 525 mm | 565 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 71 ° | 71 ° | 71 ° | 71.5 ° |
| Head Tube Length | 110 mm | 115 mm | 115 mm | 125 mm | 135 mm | 145 mm |
| Chainstay Length | 424 mm | 424 mm | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1046 mm | 1063 mm | 1074 mm | 1089 mm | 1104 mm | 1098 mm |
| Bottom Bracket Drop | 55 mm | 52 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 715 mm | 730 mm | 759 mm | 777 mm | 807 mm | 836 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
Model Overview
Revox 6 completes the Bergamont Revox model. There are 120 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Crosscountry bikes
Crosscountry bikes have an average weight of 12.4 kg (27.34 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 13.9 kg (30.64 lbs), Bergamont bike is considerably heavier than average. In conclusion, the average Crosscountry bike weighs 12.1% less than Revox 6.
Overview of components
Fork
Bergamont Revox 6 2021 bike is equipped with the RockShox Judy fork, and has 100mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
When it comes to wheels, the Revox 6 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
