Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 80mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
26", lite AL-6061 tubing
Suspension Fork
Suntour XCE28 DS, 80 mm, preload adjust
Drivetrain
Rear Derailleur
Shimano RD-TY300
Front Derailleur
Shimano FD-TY300
Shift Levers
Shimano SL-RV200, 3x7-speed, revo-shifter
Cassette
Sunrace CS-M40, 11-34t
Crank
Shimano FC-TY301, 42/34/24t
Bottom Bracket
Shimano BB-UN101, BSA
Chain
KMC Z7
Pedals
Wellgo LU895
Wheels
Front Hub
Shimano dynamo hub, DH-3D32, 6-bolt, disc
Rear Hub
BGM Comp, 6-bolt, disc, quick release
Rims
Shining DB-29, disc, width: 19 mm
Spokes
steel, black
Tires
Schwalbe Big Apple, reflective stripe, 50-559 Tubes: Impac AV26
Brakes
Brakes
Tektro MD-M280, mechanical disc brake, rotor: 160/160 mm
Brake Levers
Tektro, Alloy
Cockpit
Stem
Syncros 3.0, +/-6°
Handlebar
Syncros 3.0, riserbar, width: 660 mm
Grips
BGM Comp
Headset
BGM FP-H807B, A-Headset, semi-integrated, 1 1/8"
Seat
Saddle
Syncros Tofino 2.5
Seatpost
Syncros 3.0
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 38cm | 42cm | 47cm | 51cm | 56cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.5 mm | 1.49 mm | 1.48 mm | 1.46 mm |
| Bottom Bracket Height | 298 mm | 298 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 624 mm | 640 mm | 652 mm | 668 mm | 688 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 83 mm | 84 mm | 80 mm | 80 mm | 81 mm |
| Stack | 570 mm | 580 mm | 591 mm | 605 mm | 619 mm |
| Reach | 373 mm | 386 mm | 397 mm | 408 mm | 424 mm |
| Top Tube Length | 544 mm | 559 mm | 574 mm | 589 mm | 609 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 360 mm | 400 mm | 445 mm | 480 mm | 525 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 115 mm | 125 mm | 140 mm | 155 mm | 170 mm |
| Chainstay Length | 419 mm | 419 mm | 419 mm | 419 mm | 419 mm |
| Wheelbase | 1039 mm | 1055 mm | 1068 mm | 1084 mm | 1104 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 698 mm | 709 mm | 739 mm | 764 mm | 795 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Revox ATB 26 Gent belongs to the Bergamont Revox model. There are 120 bikes that carry this model name. You can get a glimpse at all models from 2021, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Crosscountry bikes average weight
The average weight for Crosscountry bikes is 12.4 kg (27.34 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 15.9 kg (35.05 lbs), the Revox ATB 26 Gent model is much heavier than average. In conclusion, the average Crosscountry bike weighs 28.23% less than Revox ATB 26 Gent.
Revox ATB 26 Gent components
Fork
This bike has the SunTour fork installed. The fork’s travel is 80mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on Revox ATB 26 Gent are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
